Post subject: 1980 fender precision special bass pickups and wiring
Posted: Thu Apr 05, 2012 5:21 pm
Offline
Hobbyist
Hobbyist

Joined: Wed Mar 28, 2012 5:17 pm
Posts: 9
I've just brought on of these basses and missing the original wiring and pickups can anyone help me in obtaining them


Top
Profile
Fender Play Winter Sale 2020
Post subject: Re: 1980 fender precision special bass pickups and wiring
Posted: Sat Apr 07, 2012 10:58 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Thu Aug 07, 2008 3:12 pm
Posts: 6355
Location: Albemarle, NC
You can contact Fender support for the diagram using the information on the Contact Us link under support.

Fender Musical Instruments Corporation
Attn: Consumer Relations Dept.
17600 N. Perimeter Drive, Suite 100
Scottsdale, AZ 85255

Telephone: (480) 596-7195
Fax: (480) 367-5262
E-mail: consumerrelations@fender.com

If they have the diagram they will send it to you. I suggest email and phoning if possible. Even with the Fender diagram, you are not in the clear since the problem you are for sure going to run into is that the stock pre-amp is no longer available. You can find equivalent OEM parts for everything but the preamp. You could find one on another bass just like it. But the better solution would be to go to an aftermarket preamp, 9 volt since you have a 9 volt slot. Frankly the stock preamps were rudimentary at best and have a reputation of eating batteries compared to today's lower drain circuitry.

Whatever modern preamp you select will have a wiring diagram that might be different from the Fender one. You could also set it up passive.

Be sure to get some white pickup covers which would be the correct look on a 1980 P-Bass Special with matching headstock.

What color?


Top
Profile
Post subject: Re: 1980 fender precision special bass pickups and wiring
Posted: Sun Apr 08, 2012 12:09 pm
Offline
Hobbyist
Hobbyist
User avatar

Joined: Sat Jul 30, 2011 2:21 am
Posts: 84
Location: The Netherlands
Hi all,

It took me some time, but I found some diagrams on the internet. I am not sure they are accurate.

See the webpage:

http://www.riverband.demon.nl/special.html


Regards,

TonH


Top
Profile
Post subject: Re: 1980 fender precision special bass pickups and wiring
Posted: Sun Apr 08, 2012 11:49 pm
Offline
Hobbyist
Hobbyist

Joined: Wed Mar 28, 2012 5:17 pm
Posts: 9
Hey thanks for the help set me on the way anymore info or the pickups and wiring be cool


Top
Profile
Post subject: Re: 1980 fender precision special bass pickups and wiring
Posted: Mon Apr 09, 2012 10:26 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Thu Aug 07, 2008 3:12 pm
Posts: 6355
Location: Albemarle, NC
Yes that appears to be the correct diagram. I'd decide on what preamp to use, then see their suggested wiring schematic.


Top
Profile
Post subject: Re: 1980 fender precision special bass pickups and wiring
Posted: Tue Apr 10, 2012 1:54 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Thu Dec 31, 2009 10:34 pm
Posts: 10760
Location: Athens, Greece
@brotherdave

Did the Special and Elite basses were the precursors to the modern active P and Js?


Top
Profile
Post subject: Re: 1980 fender precision special bass pickups and wiring
Posted: Tue Apr 10, 2012 2:39 pm
Offline
Hobbyist
Hobbyist
User avatar

Joined: Sat Jul 30, 2011 2:21 am
Posts: 84
Location: The Netherlands
@chromeface:

According to this article of Fender they are:

http://www.fender.com/en-NL/news/index.php/?display_article=819

Back at Fender headquarters in the United States, the early ’80s was a busy time. The company introduced its first bass model with active electronics, the Precision Bass Special, in 1980, and Fender very soon abandoned the three-bolt neck-mounting system adopted in the early 1970s; returning to the classic four-bolt method for all of its bass guitars.


Top
Profile
Post subject: Re: 1980 fender precision special bass pickups and wiring
Posted: Tue Apr 10, 2012 9:31 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Thu Aug 07, 2008 3:12 pm
Posts: 6355
Location: Albemarle, NC
chromeface wrote:
@brotherdave

Did the Special and Elite basses were the precursors to the modern active P and Js?


Yes. The 1980 P-Bass Special would be the granddaddy yes. First active Fender bass. Very nice instrument at the time and still capable. The preamp's battery life was much shorter than more modern preamps that are far more efficient.


Top
Profile
Post subject: Re: 1980 fender precision special bass pickups and wiring
Posted: Thu Apr 12, 2012 6:40 am
Offline
Hobbyist
Hobbyist

Joined: Tue Jan 25, 2011 8:00 am
Posts: 27
I have a couple extra of the 2-band pre-amps for a P-Bass Special, if you are interested. I got them with mine.


Top
Profile
Post subject: Re: 1980 fender precision special bass pickups and wiring
Posted: Thu Apr 12, 2012 7:55 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Thu Dec 31, 2009 10:34 pm
Posts: 10760
Location: Athens, Greece
The Rocco Prestia signature Precision looked similar except the jack is side-mounted, the active/passive switch is absent and the split humbucker is reversed.


Top
Profile
Post subject: Re: 1980 fender precision special bass pickups and wiring
Posted: Sat Apr 14, 2012 1:25 pm
Offline
Hobbyist
Hobbyist

Joined: Tue Jan 25, 2011 8:00 am
Posts: 27
Here is a picture of the preamp that is in the P-Bass Specials from 1980-1983.


Top
Profile
Post subject: Re: 1980 fender precision special bass pickups and wiring
Posted: Sun Nov 08, 2015 7:24 pm
Offline
Hobbyist
Hobbyist

Joined: Sun Nov 08, 2015 7:21 pm
Posts: 1
Hi Gougedeye,

Do you still have a 1980 Precision Special pre-amp available?

I have a problem with mine and I am looking for a replacement.

Thanks!
