Post subject: TBX control with Lace Sensor Gold Pick-ups.
Posted: Wed Jan 22, 2014 3:56 am
Offline
Roadie
Roadie

Joined: Wed Jan 04, 2012 6:47 pm
Posts: 248
Any one here have just the TBX control with there Lace Sensor pickups? If you do, how does it sound. Also do I need to install the Booster controll to get a good sound?


Top
Profile
Fender Play Winter Sale 2020
Post subject: Re: TBX control with Lace Sensor Gold Pick-ups.
Posted: Wed Jan 22, 2014 6:00 am
Offline
Professional Musician
Professional Musician
User avatar

Joined: Tue Jul 17, 2007 4:54 am
Posts: 2573
Location: Laurel, MD
This was the basic set up for the old Stratocaster Plus, and worked perfectly. I've owned a Strat Plus and currently own an Eric Clapton Strat with gold Lace Sensors, and both sound wonderful without the mid-range boost.

I hope this helps.


Top
Profile
Post subject: Re: TBX control with Lace Sensor Gold Pick-ups.
Posted: Wed Jan 22, 2014 10:51 am
Offline
Roadie
Roadie

Joined: Wed Jan 04, 2012 6:47 pm
Posts: 248
paris wrote:
This was the basic set up for the old Stratocaster Plus, and worked perfectly. I've owned a Strat Plus and currently own an Eric Clapton Strat with gold Lace Sensors, and both sound wonderful without the mid-range boost.

I hope this helps.

The TBX controls all the pickups or just the Neck Middle? How should I connect the TBX?


Top
Profile
Post subject: Re: TBX control with Lace Sensor Gold Pick-ups.
Posted: Wed Jan 22, 2014 11:14 am
Offline
Professional Musician
Professional Musician
User avatar

Joined: Tue Jul 17, 2007 4:54 am
Posts: 2573
Location: Laurel, MD
I seem to remember the TBX tone pot was located in the 2nd tone pot position on the Strat Plus and in the Eric Clapton Strat is located in the 1st tone pot position.

I would go online and find a wiring diagram for a Strat Plus first. The Clapton Strat will have the mid-range boost kit as part of the diagram, and believe me, you want as little confussion as possible when looking at a wiring diagram.

Good luck!


Top
Profile
Post subject: Re: TBX control with Lace Sensor Gold Pick-ups.
Posted: Wed Jan 22, 2014 12:37 pm
Offline
Rock Icon
Rock Icon
User avatar

Joined: Thu Dec 31, 2009 10:34 pm
Posts: 10760
Location: Athens, Greece
On the Plus, Deluxe Plus, Ultra and Jeff Beck signature models the TBX affects the middle/bridge pickups. Neck pickup is hooked into a standard tone pot.

On certain Strats with active electronics the TBX affects the overall signal compensating the lack of highs when the MDX pot is cranked up.

There are exceptions, though: Clapton no longer uses the TBX on his guitars since March 2000. The MDX pot is still present but the TBX has been replaced with a standard tone pot.



Top
Profile
Post subject: Re: TBX control with Lace Sensor Gold Pick-ups.
Posted: Wed Jan 22, 2014 2:18 pm
Offline
Roadie
Roadie

Joined: Wed Jan 04, 2012 6:47 pm
Posts: 248
Is it possible to install a TBX for the front pickup and a TBX for the Mid and Bridge pickup? I was also thinking of installing a no-load pot for the bridge pickup, and a TBX for the neck and mid pickup.


Top
Profile
Post subject: Re: TBX control with Lace Sensor Gold Pick-ups.
Posted: Wed Jan 22, 2014 2:25 pm
Offline
Roadie
Roadie

Joined: Wed Jan 04, 2012 6:47 pm
Posts: 248
Or maybe a better guestion would be...How do I brighten up the sound for the neck mid postion pickups and the mid and bridge postion?


Top
Profile
Post subject: Re: TBX control with Lace Sensor Gold Pick-ups.
Posted: Wed Jan 22, 2014 8:48 pm
Offline
Hobbyist
Hobbyist
User avatar

Joined: Fri Feb 22, 2013 10:31 am
Posts: 5
I like it,but i replace volumen to 500k i thinks open a bit more the sound of the pickups.


Top
Profile
Post subject: Re: TBX control with Lace Sensor Gold Pick-ups.
Posted: Thu Jan 23, 2014 2:28 am
Offline
Hobbyist
Hobbyist

Joined: Thu Oct 28, 2010 5:09 am
Posts: 58
chromeface wrote:
There are exceptions, though: Clapton no longer uses the TBX on his guitars since March 2000. The MDX pot is still present but the TBX has been replaced with a standard tone pot.



I didn't know that, how come his signature Strats still come with the TBX if he prefers a standard tone pot? It seems counterintuitive to me because the TBX pot gives you standard tone control functionality (low pass) as well as the additional high pass option.


Top
Profile
Post subject: Re: TBX control with Lace Sensor Gold Pick-ups.
Posted: Thu Jan 23, 2014 10:27 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Thu Dec 31, 2009 10:34 pm
Posts: 10760
Location: Athens, Greece
Sebber wrote:
I didn't know that, how come his signature Strats still come with the TBX if he prefers a standard tone pot?


Those features are specified by old slowhand himself.

Only the EC Standards and Team Built EC Customs sport the TBX.

Masterbuilts (guitars built for the artist) employ a regular tone control.

Quote:
It seems counterintuitive to me because the TBX pot gives you standard tone control functionality (low pass) as well as the additional high pass option.


The TBX was removed for the following reasons:

1. Tone was too muddy.

2. The VNs make the high-end sparkle provided by the high pass filter obsolete.


Top
