Now my working hours have stabilised (a bit) I've had some free time to work on the Strat. So time to resurrect this thread from page 5 to the top with an update for ya! :D

Chapter (4) Body Shaping – Continued

I did say that the shaping would all be done by hand....

….I lied!

Introducing, the Big Hairy Drill Jig!


The subject of Drill Jigs came up in Kozy's thread to ensure nice straight drill holes were made for the bridge screws. I've been thinking about building / buying one for a while when Ceri mentioned his Axminster catalog. I'd totally forgot to look for one there. I ended up buying their Drill Guide for a very reasonable price and then made a jig for my needs.


With the drill mounted like this I can use a drum sander to make the tummy cut far easier than by hand (which takes a “hand cramping-ly long time)


With the drum sander and the drill jig it takes about 30mins to achieve this....


The Big Hairy Drill Jig rules!

There are some high spots that need to be dealt with. So I've made myself a scraper from an old saw blade, as instructed by Jake at Acacia Designs (the top chap who sold me the piece for the inlay) to plane them out



I also used the scraper to bevel the edge over. It a great tool. Love it!


A quick rub with some 180 fine sand paper....


….and the tummy cut is pretty much there bar some finer sanding that will get done later along with the rest of the body once the all the shaping is sorted.

I've got more to post but its getting late so I'll post the rest of what I've got over the next couple of days

Enjoy!

Andy & Randel the Cat
