Post subject: Blues Junior Foot Switch Jack Extension to back panel
Posted: Sun Aug 11, 2013 12:58 pm
Offline
Hobbyist
Hobbyist

Joined: Mon Dec 19, 2011 9:06 pm
Posts: 4
I would like to extend my foot switch jack so that I can just plug it in the rear panel. Can I just drill a hole in the back install a Switchcralt 1/4" output jack then solder to a open end cable with a 1/4 plug inserted into the foot switch jack input?


Top
Profile
Fender Play Winter Sale 2020
Post subject: Re: Blues Junior Foot Switch Jack Extension to back panel
Posted: Sun Aug 11, 2013 1:35 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Mon Jan 12, 2009 4:50 pm
Posts: 7998
Location: ʎɹʇunoɔ ǝsoɹ pןıʍ
I assume you wish to do this for the sake of convenience seeing that the jack is a little bit awkward to get at. Rather than drill into your amp and hack it up why not just leave the cable plugged into the jack and tuck the cable inside the cabinet when not in use?

_________________
Just think of how awesome a guitar player you could have been by now if you had only spent the last 10 years practicing instead of obsessing over pickups and roasted maple necks.


Top
Profile
Post subject: Re: Blues Junior Foot Switch Jack Extension to back panel
Posted: Sun Aug 11, 2013 1:37 pm
Offline
Rock Star
Rock Star

Joined: Mon Apr 05, 2010 2:37 pm
Posts: 8708
Location: Natural Bridge, Virginia
1. First of all, you would have to completely disassemble the amplifier removing the chassis from the cabinet and the PCB and all components from the chassis. Metal shavings and electricity don't go well together.

2. You need to use a shorting jack per the schematic (You do know how to read a schematic, right?).

http://support.fender.com/schematics/gu ... ematic.pdf

3. How do you propose to get a cable that is plugged into the front of the amp around to the back jack? It would be better to run a shielded jumper cable inside the amp from the front jack to the back jack which will require more disassembly/assembly.

Frankly, it doesn't seem worth the effort to me.

Why do people continue to post amp questions in the Lounge when there are two dedicated amp forums here?

_________________
Bill



Top
Profile
Post subject: Re: Blues Junior Foot Switch Jack Extension to back panel
Posted: Sun Aug 11, 2013 1:37 pm
Offline
Rock Star
Rock Star

Joined: Mon Apr 05, 2010 2:37 pm
Posts: 8708
Location: Natural Bridge, Virginia
BMW-KTM wrote:
I assume you wish to do this for the sake of convenience seeing that the jack is a little bit awkward to get at. Rather than drill into your amp and hack it up why not just leave the cable plugged into the jack and tuck the cable inside the cabinet when not in use?


Excellent suggestion. :wink:

_________________
Bill



Top
Profile
Post subject: Re: Blues Junior Foot Switch Jack Extension to back panel
Posted: Sun Aug 11, 2013 1:58 pm
Offline
Rock Icon
Rock Icon
User avatar

Joined: Wed Mar 31, 2010 12:48 am
Posts: 26417
Location: Tombstone Territory
BMW-KTM wrote:
Rather than drill into your amp and hack it up why not just leave the cable plugged into the jack and tuck the cable inside the cabinet when not in use?



:lol:

Arjay

_________________
"Here's why reliability is job one: A great sounding amp that breaks down goes from being a favorite piece of gear to a useless piece of crap in less time than it takes to read this sentence." -- BRUCE ZINKY


Top
Profile
Post subject: Re: Blues Junior Foot Switch Jack Extension to back panel
Posted: Sun Aug 11, 2013 3:15 pm
Offline
Hobbyist
Hobbyist

Joined: Mon Dec 19, 2011 9:06 pm
Posts: 4
I solved my own question I had a 4" 1/4" male to female plugged one end into the switch jack and the switch plug into the other and it works fine


Top
Profile
Post subject: Re: Blues Junior Foot Switch Jack Extension to back panel
Posted: Sun Aug 11, 2013 3:24 pm
Offline
Rock Icon
Rock Icon
User avatar

Joined: Wed Mar 31, 2010 12:48 am
Posts: 26417
Location: Tombstone Territory
Another innocent Fender amp spared the indignity of a blasphemous power tool on the prowl!

Rawk on!

8)

Arjay

_________________
"Here's why reliability is job one: A great sounding amp that breaks down goes from being a favorite piece of gear to a useless piece of crap in less time than it takes to read this sentence." -- BRUCE ZINKY


Top
Profile
Post subject: Re: Blues Junior Foot Switch Jack Extension to back panel
Posted: Sun Aug 11, 2013 4:41 pm
Offline
Professional Musician
Professional Musician
User avatar

Joined: Tue May 24, 2011 8:25 pm
Posts: 1099
Location: A cloud of eider down
Retroverbial wrote:
Another innocent Fender amp spared the indignity of a blasphemous power tool on the prowl!

Rawk on!

8)

Arjay

How right you are!!!


_________________
"Where would rock and roll be without feedback?"


Top
Profile
Post subject: Re: Blues Junior Foot Switch Jack Extension to back panel
Posted: Sun Aug 11, 2013 5:29 pm
Offline
Rock Star
Rock Star

Joined: Mon Apr 05, 2010 2:37 pm
Posts: 8708
Location: Natural Bridge, Virginia
Funkyard wrote:
I solved my own question I had a 4" 1/4" male to female plugged one end into the switch jack and the switch plug into the other and it works fine


And this accomplished what? :?

_________________
Bill



Top
Profile
