Post subject: Re: Triple P-90 Strat (BUILD BEGINS, PICS!)
Posted: Thu Jun 20, 2013 12:43 am
Offline
Aspiring Musician
Aspiring Musician

Joined: Tue Aug 07, 2012 3:08 pm
Posts: 474
I LOVE the plush sound of soapbar pickups. A Strat with 3 of them is a brilliant idea.


Top
Profile
Fender Play Winter Sale 2020
Post subject: Re: Triple P-90 Strat Project!
Posted: Thu Jun 20, 2013 4:41 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Thu Jul 26, 2007 4:57 am
Posts: 13164
Location: Peckham: where the snow leopards roam
texasguitarslinger wrote:
I've done a little bit of research, and I'm 99% sure that I'm going to need to have someone put a clear coat over it once it's applied. Robert usually doesn't do anything like that. He said he would be willing to try, but warned me that I might have to buy another decal if he messes up. I'll talk to him about it again. It could be that if he's not comfortable doing it, I'll drop the neck off with the guy who did my Forumcaster and have him install it. Unfortunately, I'll be stuck waiting for a guitar to dry again.

Hi TGS: this is no problem at all and something you can very easily do yourself if you want.

As we know, waterslide decals usually don't like nitrocellulose - in fact, they sort of melt and wither up if you spray nitro over them, which is why Fender put the decal uncovered on top of the lacquer back in the '50s and '60s, until they started using polyurethane on necks. So you need to know whether your neck is lacquered with nitro or urethane: just put a small drop of naphtha (nail varnish remover is the same thing) on the varnish in a spot on the heel where it will be hidden inside the neck pocket later. If it dissolves the lacquer then it's nitro; if not, it's urethane.

If it's urethane you can just clean the front of the headstock and proceed from there. If it's nitro you need to spray a single thin coat of urethane on the front first and then put the decal on that.

You can buy urethane very affordably and conveniently in an aerosol. Many brands are available; Plasti Kote Polyurethane Varnish in gloss or satin is a good one and easy to find in hardware shops or on the internet - even Ebay and Amazon. This:


Once you have a tin of that it's very handy to have around for little refin and touch-up jobs on urethane finished guitars (which is most of them), so it's not a waste for you or Robert to buy it.

As I said, if your neck is nitro lacquered you need a thin coat of urethane on the front of the headstock first, right over the top of the nitro. No need to sand back or anything tiresome, but make sure it's clean (wipe it thoroughly with denatured spirit). If it's already urethane, go right ahead and slip the decal on there. Once it's set you simply spray around three thin coats of the aerosol stuff over the top. Let it dry for a few hours. You will find that the edge of the decal is rather apparent through the varnish, so if that bothers you now just sand it a little very gently with some P600 paper to knock it back a bit and soften that edge. Then spray two or three more thin layers.

You can carry on repeating that process till you have a mirror-smooth headstock face, or if you don't mind the decal edge coming through a bit then leave it after just the first three coats. That's all you actually need to seal the decal in and protect it.

This task is easier and almost as quick as typing this post has been. Nuttin' to be nervous of, and well within your excellent capabilities. Have at it! :D

Cheers - C

_________________


Top
Profile
Post subject: Re: Triple P-90 Strat (BUILD BEGINS, PICS!)
Posted: Fri Jun 21, 2013 3:22 am
Offline
Amateur
Amateur
User avatar

Joined: Sat Jun 01, 2013 5:15 am
Posts: 195
I can't wait to see the finished product.


Top
Profile
Post subject: Re: Triple P-90 Strat (BUILD BEGINS, PICS!)
Posted: Mon Jun 24, 2013 1:16 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Sun Jan 04, 2009 10:27 pm
Posts: 3355
Location: Houston, Texas
Ceri, I did some more research on it and I think I feel a lot more comfortable about applying the decal now. Thanks for the tips! I'm fairly sure the neck is urethane, but I'll test it anyway. It doesn't really say in the description. http://www.allparts.com/SRF-S-Replacement-Neck-for-Stratocaster_p_3495.html

Sorry I didn't get to post an update sooner, I've had another busy weekend! Last Thursday we selected a bone nut which Robert was about to craft when my boss came by and made a comment about how the finish had a sort of nasty orange peel look to it. Orange peel is a term used to describe a finish which hasn't been polished out properly. It's kind of an in between of satin and gloss, and generally it's not desirable.

In the back of the shop, we have an industrial guitar buffing machine (the same kind they use in the Gibson factory!) and Robert said he could probably buff the body out to get more of a gloss finish. It still won't be perfect or up the par with my custom Strat, but from what he had a chance to do Thursday it made a big difference! So buffing was really the only thing we ended up doing that day and unfortunately I don't have any pics of the actual guitar since the difference is very subtle and I was having a hard time getting it to show up in pics.

But here's what a guitar with an orange peel finish looks like vs. one with a gloss finish. Neither guitar is mine.


We might continue work on it tomorrow depending on much of Robert's other work he has in the shop.

_________________
Website: http://www.rebeccalaird.com
Facebook: https://www.facebook.com/rebeccalairdmusic
Twitter: https://twitter.com/beckslaird
Instagram: http://instagram.com/beckslaird


Top
Profile
Post subject: Re: Triple P-90 Strat (BUILD BEGINS, PICS!)
Posted: Thu Jun 27, 2013 8:52 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Sun Jan 04, 2009 10:27 pm
Posts: 3355
Location: Houston, Texas
No work today because Robert had an influx of new repairs over the weekend (which is actually a great thing for the shop). But something came in the mail today. Hmm, I wonder what this could be?

It's the decals!

_________________
Website: http://www.rebeccalaird.com
Facebook: https://www.facebook.com/rebeccalairdmusic
Twitter: https://twitter.com/beckslaird
Instagram: http://instagram.com/beckslaird


Top
Profile
Post subject: Re: Triple P-90 Strat (BUILD BEGINS, PICS!)
Posted: Fri Jun 28, 2013 7:32 am
Offline
Amateur
Amateur

Joined: Mon Dec 20, 2010 9:31 am
Posts: 176
Love the decals! Can't wait to see the finished product.


Top
Profile
Post subject: Re: Triple P-90 Strat (BUILD BEGINS, PICS!)
Posted: Fri Jun 28, 2013 8:24 am
Offline
Rock Star
Rock Star
User avatar

Joined: Fri Jul 20, 2007 12:56 pm
Posts: 4033
Location: 16 Miles North Of The Red River
texasguitarslinger wrote:
No work today because Robert had an influx of new repairs over the weekend (which is actually a great thing for the shop). But something came in the mail today. Hmm, I wonder what this could be?

It's the decals!

AWESOMENESS INCARNATED!

Love the name...especially since it has a connotation to SRV's pre-Double Trouble group...

_________________
Good Vibes To Y'all!


Screamin' Armadillos
Texas Roadhouse Music
Guitar/Slide Guitar/Harp/Vocals


Top
Profile
Post subject: Re: Triple P-90 Strat (BUILD BEGINS, PICS!)
Posted: Fri Jun 28, 2013 6:48 pm
Offline
Rock Icon
Rock Icon
User avatar

Joined: Thu Jan 29, 2009 7:13 pm
Posts: 19026
Location: Illinois, USA
Looking very good Texas!

_________________
you can save the world with your guitar one love song at a time it's just better, more fun, easier with a fender solid body electric guitar or electric bass guitar.


Top
Profile
Post subject: Re: Triple P-90 Strat (BUILD BEGINS, PICS!)
Posted: Fri Jun 28, 2013 10:00 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Sun Jan 04, 2009 10:27 pm
Posts: 3355
Location: Houston, Texas
Screamin' Armadillo wrote:
Love the namespecially since it has a connotation to SRV's pre-Double Trouble group...


That was the idea. ;)

_________________
Website: http://www.rebeccalaird.com
Facebook: https://www.facebook.com/rebeccalairdmusic
Twitter: https://twitter.com/beckslaird
Instagram: http://instagram.com/beckslaird


Top
Profile
Post subject: Re: Triple P-90 Strat (BUILD BEGINS, PICS!)
Posted: Wed Jul 10, 2013 12:37 am
Offline
Rock Star
Rock Star
User avatar

Joined: Sun Jan 04, 2009 10:27 pm
Posts: 3355
Location: Houston, Texas
Finally another update! We're making slow progress since Robert's work has picked up. He got the tuning machines just about installed, but he had to stop at the final step because we didn't have the smaller dremel bit that he needed. We have it now though, so hopefully we'll make some progress this week.

Allparts necks come with holes too small to fit modern Fender tuning machines, so we had to widen them. Robert used some painter's tape as a guide.


And here they are finished! They're not perfectly round, but you won't be able to tell once the tuning machines are on.


After the holes were drilled, Robert carefully aligned the tuning machines and tapped on them with a fretting tool (it looks like a small hammer) so that the two little posts that sit in the wood left indentations. He used the indentations as a reference to drill these smaller holes.


Again, not perfect, which is why we need that smaller bit to fine tune it. Hopefully we can pick everything back up in a couple of days.

_________________
Website: http://www.rebeccalaird.com
Facebook: https://www.facebook.com/rebeccalairdmusic
Twitter: https://twitter.com/beckslaird
Instagram: http://instagram.com/beckslaird


Top
Profile
Post subject: Re: Triple P-90 Strat (BUILD BEGINS, PICS!)
Posted: Thu Jul 11, 2013 1:38 pm
Offline
Professional Musician
Professional Musician
User avatar

Joined: Mon Jul 30, 2007 6:07 am
Posts: 1747
Location: Central WI
That is really looking sharp. I wish I had that many photos of the progress during the refinish on my Musicmaster bass.

Thanx!


Top
Profile
Post subject: Re: Triple P-90 Strat (BUILD BEGINS, PICS!)
Posted: Thu Jul 11, 2013 10:06 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Sun Jan 04, 2009 10:27 pm
Posts: 3355
Location: Houston, Texas
It's finished! (All but the decal installation that is.) Now I'm just waiting for the pictures to upload...

_________________
Website: http://www.rebeccalaird.com
Facebook: https://www.facebook.com/rebeccalairdmusic
Twitter: https://twitter.com/beckslaird
Instagram: http://instagram.com/beckslaird


Top
Profile
Post subject: Re: Triple P-90 Strat (ALMOST FINISHED, PICS!)
Posted: Fri Jul 12, 2013 2:21 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Thu Jan 29, 2009 7:13 pm
Posts: 19026
Location: Illinois, USA
Thanks Texas, cool update! 8)

_________________
you can save the world with your guitar one love song at a time it's just better, more fun, easier with a fender solid body electric guitar or electric bass guitar.


Top
Profile
Post subject: Re: Triple P-90 Strat (ALMOST FINISHED, PICS!)
Posted: Fri Jul 12, 2013 5:03 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Mon Jul 16, 2007 6:51 pm
Posts: 25353
Location: Witness Protection Program
Lookin' fine! 8)

_________________
Being able to play and enjoy music is a gift that's often taken for granted.

Don't leave home without it!


Top
Profile
Post subject: Re: Triple P-90 Strat (ALMOST FINISHED, PICS!)
Posted: Fri Jul 12, 2013 4:33 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Sun Jan 04, 2009 10:27 pm
Posts: 3355
Location: Houston, Texas
It only took two hours for the photos to upload last night. :shock: That's what happens when your internet connection is stuck in the 90's!

Anyway, here are the pics of the last bit of assembly! Sorry in advance for the load time of this page.

Robert went ahead and installed the tuning machines before I got there, and got the nut rough cut.


He needed to get the neck on, so he had to clamp it on with this jig to get the holes drilled. What you don't see here is how he had to spend about half an hour trying to scrape finish out of the neck pocket to make it work.

Now to make sure the neck is aligned properly. We added two throw away strings to make sure everything was right.

Next the pickups were installed with P-90 wood screws. I had no luck finding inserts, so I have to be careful adjusting them. I don't think I'll need to though, Robert got the pickup height adjusted when he did the set up on it later.

Since I lacked the proper springs to get the P-90s to sit right, we improvised with some foam inserts. It's a temporary solution, but it gives me time to find those springs! Plus foam gives it a nice, squishy, soft tone. :lol:

It actually looked sort of cool without a pickguard too!

More to come...
