Post subject: I have an idea for an up top trem system. Modern Bigsby?
Posted: Tue Jun 19, 2012 8:55 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Fri Sep 16, 2011 7:10 pm
Posts: 5057
Location: The Capital Wasteland
Alright, so I was just looking at parts, particularly the spring claw from a Stratocaster, when it came to me. "What if I mounted this up top?" Well, I thought of a whole system for it, possibly.

It started with this basic hardtale bridge.


Remove the saddles from it, make it a solid bar of steel, maybe one inch thick and three inches long. Keep the wraparound feature for the strings.

Now, move to the Tune o Matic.


Use this for the obvious feature, saddle adjustment for making your guitar playable.

Now, here's where the fun begins.


Take this, and mount it so that the claw faces away from the bridge. Take your springs, and elongate them, and possibly bend the mounting ring, so that the actual spring can hook to the steel bar, with holes drilled in the appropriate places for them, of course.

So it pivots smoothly, I was thinking mount the system in some kind of ball bearing system. I'm not sure what the mountings are called, but I'll show a crude sketch I made..

So you can mount your trem arm, the low side of the bar will be slightly elongated and drilled to accommodate.


If you use my idea, and make money, be sure to send me enough so I can live comfortably and take care of my mama. :P If you make a bunch of one offs, send me one!

(also have a few other complicated ideas, my inventive side takes over when I have too much time to think.)

(also, don't make fun of my three minutes of drawing!)
