yeah...more pics to come.

_________________
RK

2007 Fender Highway 1
2012 American Deluxe
2015 MIM Dave Murray HHH
2010 Fender Blacktop
1987 Fender Avalon Acoustic
2012 Marshall DSL 15 watt head


Top
Profile
Fender Play Winter Sale 2020
Post subject: Re: Somebody talk some sense into me... (Almost there!)
Posted: Mon Feb 06, 2012 11:17 pm
Offline
Rock Icon
Rock Icon
User avatar

Joined: Thu Jan 29, 2009 7:13 pm
Posts: 19026
Location: Illinois, USA
Texas, those pics are awesome! Your guitar guy applied the decals perfectly! That is the best Strat body that I've seen! Thanks for posting those pics and looking forward to seeing the new "Becks" model completed. :D

_________________
you can save the world with your guitar one love song at a time it's just better, more fun, easier with a fender solid body electric guitar or electric bass guitar.


Top
Profile
Post subject: Re: Somebody talk some sense into me... (Almost there!)
Posted: Tue Feb 07, 2012 12:41 pm
Offline
Professional Musician
Professional Musician
User avatar

Joined: Fri Oct 08, 2010 12:45 am
Posts: 2244
Location: Pittsburg, CA
Very nice! I can't wait to see it all put together! Then a sound clip is definitely in order. Congrats, I know you must be stoked!

_________________
Check out my new FB music page!

https://www.facebook.com/TheDevilandMe.Music



Top
Profile
Post subject: Re: Somebody talk some sense into me... (Almost there!)
Posted: Wed Feb 08, 2012 12:41 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Fri Mar 06, 2009 12:01 pm
Posts: 3261
Location: Halls of ikea
Great looking decals Becks, looking forward to seeing the finished Strat in all it's glory


Top
Profile
Post subject: Re: Somebody talk some sense into me... (Almost there!)
Posted: Wed Feb 08, 2012 1:18 pm
Offline
Professional Musician
Professional Musician
User avatar

Joined: Fri Jun 20, 2008 11:08 am
Posts: 2265
That's a nice looking guitar miss Tex,
I've missed the whole ride, but I'm happy for you.
I'm sure your gonna rock out on that beck-ocaster.
Hope I wrote right.

_________________
"Yesterday is history, tomorrow is a mystery, but today is a gift. That is why it is called the present."

oogway, kungfu panda 2008


Top
Profile
Post subject: Re: Somebody talk some sense into me... (Almost there!)
Posted: Wed Feb 08, 2012 3:24 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Sun Jan 04, 2009 10:27 pm
Posts: 3355
Location: Houston, Texas
Well, my repair tech is really tied up this week. He has three assemblies, including mine, and about 12 other repairs waiting from input jack replacements to full setups. He said he's going to try to work on mine this Friday, so I have a couple more days to wait.

_________________
Website: http://www.rebeccalaird.com
Facebook: https://www.facebook.com/rebeccalairdmusic
Twitter: https://twitter.com/beckslaird
Instagram: http://instagram.com/beckslaird


Top
Profile
Post subject: Re: Somebody talk some sense into me... (Almost there!)
Posted: Fri Feb 10, 2012 11:51 pm
Offline
Rock Icon
Rock Icon
User avatar

Joined: Thu Jan 29, 2009 7:13 pm
Posts: 19026
Location: Illinois, USA
Sounds promising Texas :D

_________________
you can save the world with your guitar one love song at a time it's just better, more fun, easier with a fender solid body electric guitar or electric bass guitar.


Top
Profile
Post subject: Re: Somebody talk some sense into me... (Almost there!)
Posted: Sat Feb 11, 2012 3:55 am
Offline
Professional Musician
Professional Musician
User avatar

Joined: Fri Aug 13, 2010 11:07 am
Posts: 1530
Location: On a pebbly beach, UK
http://www.youtube.com/watch?v=Hz64hWng ... ata_player

8) :D :wink:

All in good time, TGS. We're only hanging' on the edge of our seats…

:D

Cheers

Nutter


Top
Profile
Post subject: Re: Somebody talk some sense into me... (Almost there!)
Posted: Sat Feb 11, 2012 9:24 am
Offline
Rock Star
Rock Star
User avatar

Joined: Sun Jan 04, 2009 10:27 pm
Posts: 3355
Location: Houston, Texas
The assembly stage has begun! I'm at work now, but I'll get the pics posted as soon as I get home this evening. :D

_________________
Website: http://www.rebeccalaird.com
Facebook: https://www.facebook.com/rebeccalairdmusic
Twitter: https://twitter.com/beckslaird
Instagram: http://instagram.com/beckslaird


Top
Profile
Post subject: Re: Somebody talk some sense into me... (Almost there!)
Posted: Sun Feb 12, 2012 12:04 am
Offline
Rock Star
Rock Star
User avatar

Joined: Sun Jan 04, 2009 10:27 pm
Posts: 3355
Location: Houston, Texas
Okay, finally! The detailed rundown on Day 1 of the build.

(Beware of giant pictures! :lol: )

The first thing we decided to tackle was fitting the neck to the body. It fit perfectly (but tightly) before the paint, but after the paint I couldn't fit the neck into the pocket anymore. That's because there was a thin coat of paint on the sides on the pocket and on the neck right where it joins the body. It also may have caused the wood to swell a bit. In any case, we had to sand the excess paint out of the pocket to finally fit the neck. It was a lot longer and more tedious than I expected, it probably took about an hour and a half before we got the neck to drop into the pocket without forcing it.

Here's the pocket about five minutes into sanding. At that point we were just focusing on that left side.


And here's my guitar tech sanding down the other side. He even had to use a dremel on the side closest to the pickups, since it would be too awkward trying to get the tiny sanding block back there.


Finally, they fit!


Next, we installed the tremolo assembly. This was probably the easiest part of assembly so far. The holes lined up, and everything was really straight forward. It was finished (including soldering the ground) within about fifteen minutes.

Here it is placed without being installed yet, and the pickguard is just there to see how it will look.


The back of the tremolo before adding the claw.


The front with the ground and claw installed.


And the back after the ground and claw were installed.


Unfortunately (or fortunately depending on how you look at it) we had about one more hour left to work on it before I had to begin teaching lessons for a teacher who was out of town. The final thing we were able to complete was installing the tuning machines.

The first thing to do was to fit the tuners and remove more excess paint with the dremel tool.


Next, we make sure all the tuners are aligned.


The little feet on the bottom keep the tuning machine in place after holes are drilled for them. Here's a closeup before the holes were drilled.


Next, my tech took a hammer we use to get high frets down and gently tapped the tuners while they were in line so that the feet made little marks in the wood. If you look really closely, you can see them in this picture.


And then it was time for the dremel tool to make another appearance! After we had the ones on the end lined up with each other we took a straight edge (that little ruler), wrapped it in tape and used it as a guide to drill the other holes. My tech did all the work with the dremel tool, I've never handled one before and I'd rather practice on scrap wood than my custom guitar. :lol:


It took about an hour, but here's a picture of the installed tuners. The only way they could be better would be if a robot had done it, but I don't think you could tell the difference anyway. Also, a bone nut has been added by the luthier who painted it. I specifically asked for it not to be slotted because that's something I want to watch, and maybe even try, myself.


And here it is awaiting Day 2. The pickguard is just there again to get a better idea of what everything will look like when it comes together. :)


I have Wednesday and Thursday of this week off. So in all likelihood they will be Day 2 and 3 of the assembly.

_________________
Website: http://www.rebeccalaird.com
Facebook: https://www.facebook.com/rebeccalairdmusic
Twitter: https://twitter.com/beckslaird
Instagram: http://instagram.com/beckslaird


Top
Profile
Post subject: Re: Somebody talk some sense into me... (Assembly begins pg.
Posted: Sun Feb 12, 2012 2:33 am
Offline
Professional Musician
Professional Musician
User avatar

Joined: Wed Jan 05, 2011 7:42 pm
Posts: 1524
Location: OZ
Woo Hoo About time!!! "Exciting" :wink:

_________________


Top
Profile
Post subject: Re: Somebody talk some sense into me... (Assembly begins pg.
Posted: Sun Feb 12, 2012 3:59 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Thu Jan 29, 2009 7:13 pm
Posts: 19026
Location: Illinois, USA
I agree with ozrv, it certainly is exciting!

_________________
you can save the world with your guitar one love song at a time it's just better, more fun, easier with a fender solid body electric guitar or electric bass guitar.


Top
Profile
Post subject: Re: Somebody talk some sense into me... (Assembly begins pg.
Posted: Sun Feb 12, 2012 6:09 am
Offline
Rock Star
Rock Star
User avatar

Joined: Fri Jul 20, 2007 12:56 pm
Posts: 4033
Location: 16 Miles North Of The Red River
That's gonna be gorgeous! Can't wait for the next episode...

_________________
Good Vibes To Y'all!


Screamin' Armadillos
Texas Roadhouse Music
Guitar/Slide Guitar/Harp/Vocals


Top
Profile
Post subject: Re: Somebody talk some sense into me... (Assembly begins pg.
Posted: Sun Feb 12, 2012 7:04 am
Offline
Professional Musician
Professional Musician
User avatar

Joined: Fri Aug 13, 2010 11:07 am
Posts: 1530
Location: On a pebbly beach, UK
Gooooood stuff TGS! Can't wait to see the next installments!

Remind me: which pickups had you chosen to put in there? I am sure they will feel comfy in their new home! ;-)

Cheers -

Nutter


Top
Profile
Post subject: Re: Somebody talk some sense into me... (Assembly begins pg.
Posted: Sun Feb 12, 2012 6:54 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Wed Jul 18, 2007 9:53 am
Posts: 5189
Location: Magnolia, Texas (just north of Houston)
Looking good there. Can't wait for the next installment.

_________________
RK

2007 Fender Highway 1
2012 American Deluxe
2015 MIM Dave Murray HHH
2010 Fender Blacktop
1987 Fender Avalon Acoustic
2012 Marshall DSL 15 watt head
