Post subject: What is the model name of my Telecaster? **UPDATED!!**
Posted: Mon Jan 03, 2011 7:13 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Fri Jul 20, 2007 12:56 pm
Posts: 4033
Location: 16 Miles North Of The Red River
I have a 199? hecho-en-Mexico Telecaster that I love…

White blonde (almost “Mary Kaye”-like) finish that moves from vaguely see-through in the center to completely opaque on the edges (very subtle), with chrome hardware and a glossy black pickguard. Old-style Fender logo, string-through body. It feels/looks like ash, and it’s almost as heavy as an older Les Paul (but not quite).

When it was in its original configuration, it looked like a regular late 50’s-style Telecaster, except for the following:

The bridge plate is the old original style that would accept a Telecaster “Ashtray” bridge cover (like Albert Collins), except it has 6 saddles instead of only three.

It had a coil-tapped humbucker in the neck position, but it wasn’t the usual Fender “Full Range” humbucker.

It had a five-way switch (to accommodate the coil tap + various pickup combinations)

It was almost like Fender was trying to make an affordable version of Keef’s Micawber axe or Albert Collins’ Tele. I know these were production/factory features, because I’ve seen four different MIM guitars with the same switching setup/pickup/unique bridge, and I had almost bought a black-finished version of this guitar, but by the time I had the money it was gone. I bought this one in 2002 at Competition Music in Fort Worth.

I modified several things on the guitar (none of which I regret). I’m not much of a humbucker guy, and I wasn’t using the neck position very much, so I originally turned the guitar into an Esquire (removed neck pickup, replaced the pickguard with a blank one/no cutout, and added a three-way switch/wiring) and played it like that for a couple of years. Later, I put a P90 in the neck position, added 4-way Tele switching and a Fender “No-Load” tone pot (love those!) and had a neckplate engraved with my band’s Screamin’ Armadillos logo.

My questions are this:
What was this model called?

How long was it made?

How many were made?

I think it was made in 1995, but can someone confirm that for me?


Pics below (in its current state):






Thanks in advance!

_________________
Good Vibes To Y'all!


Screamin' Armadillos
Texas Roadhouse Music
Guitar/Slide Guitar/Harp/Vocals


Last edited by Screamin' Armadillo on Tue Jan 04, 2011 7:01 pm, edited 1 time in total.

Top
Profile
Fender Play Winter Sale 2020
Post subject: Re: What is the model name of my Telecaster?
Posted: Mon Jan 03, 2011 7:21 pm
Offline
Aspiring Musician
Aspiring Musician
User avatar

Joined: Wed Dec 09, 2009 10:11 am
Posts: 418
Location: Ontario
Send a Email to Fender Customer Support.

Sincerely

Telemaster


Top
Profile
Post subject: Re: What is the model name of my Telecaster?
Posted: Mon Jan 03, 2011 7:32 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Fri Jul 20, 2007 12:56 pm
Posts: 4033
Location: 16 Miles North Of The Red River
After reading another post, I found the link for the guitar's age (per the serial number).

It was made in 1995 or 1996.

I still don't have the answers to my other questions...where do I contact Fender product support?

_________________
Good Vibes To Y'all!


Screamin' Armadillos
Texas Roadhouse Music
Guitar/Slide Guitar/Harp/Vocals


Top
Profile
Post subject: Re: What is the model name of my Telecaster?
Posted: Mon Jan 03, 2011 7:36 pm
Offline
Professional Musician
Professional Musician
User avatar

Joined: Tue Mar 31, 2009 12:28 pm
Posts: 1135
Location: Sitting on my La La
Top of this page, hit the support tab then the contact us tab. Nice Tele.

Cheers,
John.E


Last edited by John.E on Mon Jan 03, 2011 7:38 pm, edited 1 time in total.

Top
Profile
Post subject: Re: What is the model name of my Telecaster?
Posted: Mon Jan 03, 2011 7:37 pm
Offline
Aspiring Musician
Aspiring Musician
User avatar

Joined: Wed Dec 09, 2009 10:11 am
Posts: 418
Location: Ontario
Screamin' Armadillo wrote:
After reading another post, I found the link for the guitar's age (per the serial number).

It was made in 1995 or 1996.

I still don't have the answers to my other questions...where do I contact Fender product support?

At the top of this page under support click contact us.


Top
Profile
Post subject: Re: What is the model name of my Telecaster?
Posted: Mon Jan 03, 2011 7:44 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Fri Jul 20, 2007 12:56 pm
Posts: 4033
Location: 16 Miles North Of The Red River
John.E wrote:
Top of this page, hit the support tab then the contact us tab. Nice Tele.

Cheers,
John.E


Thank you--for the info and for complimenting my Telecaster.

_________________
Good Vibes To Y'all!


Screamin' Armadillos
Texas Roadhouse Music
Guitar/Slide Guitar/Harp/Vocals


Top
Profile
Post subject: Re: What is the model name of my Telecaster?
Posted: Tue Jan 04, 2011 7:01 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Fri Jul 20, 2007 12:56 pm
Posts: 4033
Location: 16 Miles North Of The Red River
I got an answer from Jeff at Fender Customer Support.

The guitar is called a Tele Special. The color is called Vintage White.

I was always told I was "special", and now my guitar is, too! :lol: (But I think people are making fun of me when they say that... :? )

One of the things I found interesting was the body--it's made of poplar, with an ash veneer. I don't know anything about poplar in guitars...hmm, more research! It is a funky/cool-sounding guitar, though, and I'm very happy to have it.

What's doubly cool is the fact he traced down to the date when my guitar was made--I like that!

Kudos to Jeff and everyone who helped me with this!

Thanks and Good Vibes To Y'all!!

PS--Here's the original specs (I already detailed the pickup/switching changes I have made)

Date: 9/20/1995

Model Name: Tele® Special

Model Number: 013-5502-(Color#)

Series: Special/Deluxe Series

Body: Poplar with an Ash Veneer Top

Neck: Maple

Fingerboard: Maple (9.5” Raduis/241 mm)

No. of Frets: 21 Medium Jumbo

Scale Length: 25.5” (648 mm)

Width @ Nut: 1.650” (42 mm)

Hardware: Chrome

Machine Heads: Vintage Style

Bridge: Vintage Style

Pickguard: 3-Ply Black

Pickups: Special Design Humbucking Pickup (Neck),

Special Tele (Bridge)

Pickup Switching: Special 5 Position Blade

Positions:

1. Neck Humbucking Pickup

2. Tapped Neck Humbucking Pickup (Front Coil)

3. Bridge and Neck Pickups

4. Bridge and Tapped Neck Humbucking Pickup

5. Bridge Pickup

Controls: Master Volume, Master Tone

Colors:

(306) Black,

(307) (Vintage White),

(328) Crimson Burst,

(332) Brown Sunburst,

(Polyester Finish)

Strings: Fender Super 250L’s (.009 to .042) Nickel Plated Steel pn#073-0250-003

Unique Features:

Source: Mexico

Accessories: None

U.S. MSRP: $559.99

NOTICE: Prices and Specifications Subject to Change Without Notice

INTRODUCED: 1994

DISCONTINUED: 1/1997

_________________
Good Vibes To Y'all!


Screamin' Armadillos
Texas Roadhouse Music
Guitar/Slide Guitar/Harp/Vocals


Last edited by Screamin' Armadillo on Tue Jan 04, 2011 9:33 pm, edited 1 time in total.

Top
Profile
Post subject: Re: What is the model name of my Telecaster? **UPDATED!!**
Posted: Tue Jan 04, 2011 9:27 pm
Offline
Professional Musician
Professional Musician
User avatar

Joined: Wed Jul 18, 2007 8:07 am
Posts: 1319
Location: Inside my helmet
Jeff is also the one who got me the specs on my CS Tele, which I had been searching for. Good researcher, that guy!

_________________
Current Gear: Ron Kirn Barnbuster Tele,
Marshall: 1971 SuperLead 100>1997 1960-TV, bunch of pedals
and a 1987 Porsche 911 Carrera coupe named Veronica


Top
Profile
Post subject: Re: What is the model name of my Telecaster? **UPDATED!!**
Posted: Thu Jan 06, 2011 8:27 am
Offline
Aspiring Musician
Aspiring Musician
User avatar

Joined: Tue Jul 17, 2007 8:09 am
Posts: 453
I have the same guitar in sunburst. Btw, I think that the ash veneer is only on the bursts (which were priced slightly more than the solid colors); there's no reason to put a veneer on a solid color. Poplar can have greenish streak in the grain which makes it generally unsuitable (unless you are handpicking body wood) for grain-visible finishes, so that's the reason they used an ash veneer.


Congrats on your guitar.
