Post subject: How to make a bridge float?
Posted: Sun Feb 01, 2009 7:53 pm
Offline
Hobbyist
Hobbyist
User avatar

Joined: Fri Jun 13, 2008 12:29 pm
Posts: 81
Location: Washington PA
Is doing this a matter of taking off springs, or is there more to it? I use .10 strings if that helps at all...
Thanks in advance.

_________________
What time is it??

Time to Rock!!!!!


Top
Profile
Fender Play Winter Sale 2020
Post subject:
Posted: Sun Feb 01, 2009 8:02 pm
Offline
Professional Musician
Professional Musician
User avatar

Joined: Fri May 16, 2008 1:53 pm
Posts: 1037
Location: Southeast Missouri.
Well to make a bridge float, it is necessary to destroy it and watch it float in the water...

Naw, but seriously, I think the springs may need to be adjusted and the trem claw should be properly adjusted. I remember this from when a tech was working on making my Strat a hardtail.


Top
Profile
Post subject:
Posted: Sun Feb 01, 2009 8:42 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Wed Jul 18, 2007 9:53 am
Posts: 5189
Location: Magnolia, Texas (just north of Houston)
My instrution manual states that it should have a 1/8" float to it. Some people like it and some do not. It is a matter of loosening the claw clamp a little and possibly re-intonating the guitar. Did the guitar come with the trem flush to the body. Was it bought used? Did you change to 10's without adjusting the guitar?

This may help. Good luck

http://www.fender.com/support/stratocaster.php

_________________
RK

2007 Fender Highway 1
2012 American Deluxe
2015 MIM Dave Murray HHH
2010 Fender Blacktop
1987 Fender Avalon Acoustic
2012 Marshall DSL 15 watt head


Top
Profile
Post subject:
Posted: Sun Feb 01, 2009 9:17 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Wed Jun 13, 2007 7:02 am
Posts: 8609
Location: Vacaville, CA USA
OK, you want one bridge removed from the guitar added to a glass of root beer.



A floating bridge is a balancing act. The string tension pulls the back of the bridge up. To compensate you have springs and a claw to pull the back of the bridge back down. You can use 2, 3, 4, or 5 springs depending on how stiff you want your trem to operate. The ideal height for the back of the bridge is 1/8 of an inch. After the guitar is tuned to pitch and you have decided how many springs you want to use the claw screws are adjusted either in or out until the height of the back of the bridge is 1/8 of an inch.

_________________
Chet Feathers

Authorized TonePros Dealer
Authorized WD Music Products Dealer
F/A Official Southpaw Compliance Certification Tester http://faamps.com/

http://www.facebook.com/cafeathers


I didn't Lose my mind, I traded it for this guitar.


Top
Profile
Post subject:
Posted: Mon Feb 02, 2009 5:56 am
Offline
Aspiring Musician
Aspiring Musician
User avatar

Joined: Wed Aug 20, 2008 12:54 pm
Posts: 432
Location: Columbus, OH
CAFeathers wrote:
A floating bridge is a balancing act. The string tension pulls the back of the bridge up. To compensate you have springs and a claw to pull the back of the bridge back down. You can use 2, 3, 4, or 5 springs depending on how stiff you want your trem to operate. The ideal height for the back of the bridge is 1/8 of an inch. After the guitar is tuned to pitch and you have decided how many springs you want to use the claw screws are adjusted either in or out until the height of the back of the bridge is 1/8 of an inch.
8)


Top
Profile
Post subject:
Posted: Mon Feb 02, 2009 3:25 pm
Offline
Hobbyist
Hobbyist
User avatar

Joined: Fri Jun 13, 2008 12:29 pm
Posts: 81
Location: Washington PA
I guess i got the guitar used, handmedown from my brother, i used to use 9s but after christmas i got an 8 pack of daddrio 10s...is this extraordinarily bad for the guitar? May I ask where the claw screws are? and finally, I like to hold the Tremolo on my fathers strat and it gives it a mellower tone, would 2 or 3 springs do this for me?

_________________
What time is it??

Time to Rock!!!!!


Top
Profile
Post subject:
Posted: Mon Feb 02, 2009 3:36 pm
Offline
Professional Musician
Professional Musician
User avatar

Joined: Wed Dec 12, 2007 1:31 pm
Posts: 2122
Location: Southern California Mountains
CAFeathers wrote:
OK, you want one bridge removed from the guitar added to a glass of root beer.

:lol: :lol: :lol:

_________________
"Persistence Is The Father Of Invention"
-Crazy Old Man In Training


Top
Profile
Post subject:
Posted: Mon Feb 02, 2009 3:46 pm
Offline
Aspiring Musician
Aspiring Musician
User avatar

Joined: Wed Apr 02, 2008 12:44 pm
Posts: 559
INVINCIBLE1214 wrote:
I guess i got the guitar used, handmedown from my brother, i used to use 9s but after christmas i got an 8 pack of daddrio 10s...is this extraordinarily bad for the guitar? May I ask where the claw screws are? and finally, I like to hold the Tremolo on my fathers strat and it gives it a mellower tone, would 2 or 3 springs do this for me?


Turn the guitar over and remove the plate, (9 screws). The claw is that thing the springs connect to and is attached to the wood body of the guitar with two long wood screws. When you put heavier gage strings on, you'll need to either tighten these two screws or add another spring.

Don't worry about the heavier gage strings. Stevie Ray Vaughan was the extreme in this and used really heavy gage strings, 0.013 - 0.058 and even known to have gone as heavy as 0.018 - 0.074. However, he also tuned down a half step so he could bend a little easier. You're not going to hurt the guitar, you just need to compensate for the added stress on the bridge.

_________________
Calling an illegal alien an undocumented immigrant is like calling a drug dealer an undocumented pharmicist.


Top
Profile
Post subject:
Posted: Mon Feb 02, 2009 6:56 pm
Offline
Hobbyist
Hobbyist
User avatar

Joined: Fri Jun 13, 2008 12:29 pm
Posts: 81
Location: Washington PA
Ok, i opened up the back of my guitar, and it was pretty obvious what the claw was. So I loosened those screws, and have three springs, so that suckers floating :D Thanks for all the help guys :)

_________________
What time is it??

Time to Rock!!!!!


Top
Profile
Post subject:
Posted: Mon Feb 02, 2009 7:33 pm
Offline
Roadie
Roadie
User avatar

Joined: Sat Dec 13, 2008 9:17 am
Posts: 244
i love a nice floating bridge 8)

_________________
Fender Classic Series '50s Stratocaster, 2-Tone Sunburst
Carlos 207
Dunlop Crybaby
Digitech RP50
One WORKING Pro Junior


Top
Profile
Post subject:
Posted: Mon Feb 02, 2009 8:09 pm
Offline
Aspiring Musician
Aspiring Musician
User avatar

Joined: Thu Jul 17, 2008 7:12 pm
Posts: 838
Location: South Oregon coast
couldn't resist ;)



dang -- made myself homesick...... :(

_________________
So life is just a game, and there are many ways to play -- and all you do is choose
