Post subject: Pleading for help from AndyBigHair!
Posted: Tue Aug 14, 2012 11:16 am
Offline
Hobbyist
Hobbyist

Joined: Tue Aug 14, 2012 11:05 am
Posts: 4
I have read a few posts on this forum where Anybighair has helped - Andy, if you are out there, can you please help?

I am looking to mod my squier standard strat to the following:

Bridge - SD JB or PG
Mid- Fender Texas Special
Neck - DM ToneZone or BC

I want to use a standard 5 way switch, with the following additions:

- S1 switch to split both humbuckers when engaged, leave them full hum when not
- blender pot to add in neck/bridge
- Master Volume/Master Tone/Blend Pots

My thinking is that, if this works, I can get all of the standard "strat" single-coil sounds, plus the neck/bridge single coil "tele" sound. Also, with the full hums engaged, I can get the "fat Strat" type sounds, as well as the Neck Hum/Bridge Hum heavy-heavy sound. I have looked far and near for a wiring diagram, and can only seem to get parts of this scheme on any given wiring diagram - but never the full schematic. I will also defer to your expertise on advice for cap and pot values.

Also, no real rush on this, so take your time - I am expecting to take on this mod project around year-end.

Thanks!!


Top
Profile
Fender Play Winter Sale 2020
Post subject: Re: Pleading for help from AndyBigHair!
Posted: Thu Aug 16, 2012 10:03 am
Offline
Professional Musician
Professional Musician
User avatar

Joined: Tue Dec 01, 2009 9:22 am
Posts: 2175
Howdy & Welcome!

I reckon that's all do-able. :D

Only bit I'm not 100% on (I haven't got my wiring head with me today) is the possible phasing issues you may entail when using 3 different brands of pickup. I'm aware that both Duncan's and DiMarzio's will be out of phase with the Texas special, so I'm thinking that swapping both humbuckers hot and ground wires may sort it out.

If anyone else "In the know" is reading this, feel free to chip in and either confirm the above or set me straight, please.

Once we get that bit confirmed, I'll get started on a diagram for you.

IronSchef wrote:
Also, no real rush on this, so take your time - I am expecting to take on this mod project around year-end.

Now, that's deadline I can work with! :lol:

Cheers!

Andy

_________________
Pending Greatness


Top
Profile
Post subject: Re: Pleading for help from AndyBigHair!
Posted: Thu Aug 16, 2012 11:49 am
Offline
Hobbyist
Hobbyist

Joined: Tue Aug 14, 2012 11:05 am
Posts: 4
Thanks for the help, Andy! I do see on the SD website that if your other pups are Fender, then you need to "reverse the green and black wires on the Duncan". Also, I am wondering if I should get a middle Texas Special (RW/RP) or would getting a neck or bridge model correct the phasing?


Top
Profile
Post subject: Re: Pleading for help from AndyBigHair!
Posted: Thu Aug 16, 2012 4:06 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Tue Jul 24, 2007 7:33 am
Posts: 8461
Location: Mars, the angry red planet.
IronSchef wrote:
Thanks for the help, Andy! I do see on the SD website that if your other pups are Fender, then you need to "reverse the green and black wires on the Duncan". Also, I am wondering if I should get a middle Texas Special (RW/RP) or would getting a neck or bridge model correct the phasing?


You can dig a hole deeper and deeper here. The fact that Duncan and DiMarzios are 'naturally' out of phase with each other will render the middle single coil non-humbucking in one of either positions 2 or 4, depending on which one of the "D" brand pickups you choose to reverse the phasing on. This is directly dependent on which way the middle pickup is wound and phased. Consequently, getting a Fender RW/RP just literally reverses which combo shall give you the problem. Then comes which coil will get cut. Again, depending on which phasing you choose, depends on which coil shall be cut or retained. Here too, you would have to rewire the coil configuration of one or both of the humbuckers to not only select the proper coil you want on (or off) but then there's the old phasing issue again where even here, more wires would have to be flipped. IMO and YMMV, your best bet is to get a stack or rails single slot HB for the middle position.
