Post subject: 2010 CS LTD Clapton tone control
Posted: Fri Mar 09, 2012 1:45 pm
Offline
Amateur
Amateur

Joined: Sat Oct 03, 2009 10:49 am
Posts: 126
Location: Northern Calif
I know I have the mid-boost TBX control on my CS Clapton. But an instructor told me the signature Clapton's come with the Vol control wired to kick in a boost between 8-10. I ca't seem to tell cause it's so frigin loud :-) Can anyone confirm this?


Top
Profile
Fender Play Winter Sale 2020
Post subject: Re: 2010 CS LTD Clapton tone control
Posted: Fri Mar 09, 2012 8:15 pm
Offline
Rock Icon
Rock Icon
User avatar

Joined: Thu Dec 31, 2009 10:34 pm
Posts: 10760
Location: Athens, Greece
The Masterbuilt Clapton doesn't feature the TBX, Eric disliked the muffled "honk" from the treble/bass expander when he moved from the Lace Sensors to the Vintage Noiseless in March 2000. The active mid-boost is the so-called MDX circuit, the TBX is a passive tone pot which cuts the lows and boosts the highs or vice-versa.

Both the TBX and MDX were developed by Paul Gagon in the early 1980's.


Your guitar is a Teambuilt version of his signature Strat.


Top
Profile
Post subject: Re: 2010 CS LTD Clapton tone control
Posted: Fri Mar 09, 2012 8:49 pm
Offline
Amateur
Amateur

Joined: Sat Oct 03, 2009 10:49 am
Posts: 126
Location: Northern Calif
Thanks. My Clapton is not a Master built, it's the 2010 CS LTD, and it does have the Master TBX on Tone 1, and Master Active Mid-Boost on Tone 2.

But my question is, does the Vol pot have an extra boost at 8.


Top
Profile
Post subject: Re: 2010 CS LTD Clapton tone control
Posted: Fri Mar 09, 2012 10:24 pm
Offline
Rock Star
Rock Star

Joined: Mon Apr 05, 2010 2:37 pm
Posts: 8708
Location: Natural Bridge, Virginia
bluzdawg wrote:
But my question is, does the Vol pot have an extra boost at 8.


No.

_________________
Bill



Top
Profile
Post subject: Re: 2010 CS LTD Clapton tone control
Posted: Fri Mar 09, 2012 11:39 pm
Offline
Amateur
Amateur

Joined: Sat Oct 03, 2009 10:49 am
Posts: 126
Location: Northern Calif
Thanks Bill. Didn't think so, or you would think the spec sheet would point that feature out.


Top
Profile
Post subject: Re: 2010 CS LTD Clapton tone control
Posted: Sat Mar 10, 2012 1:07 pm
Offline
Aspiring Musician
Aspiring Musician

Joined: Fri Jul 13, 2007 12:52 am
Posts: 326
Location: Southern UK
bluesky636 wrote:
bluzdawg wrote:
But my question is, does the Vol pot have an extra boost at 8.


No.


What a beautifully precise answer! :D


Top
Profile
Post subject: Re: 2010 CS LTD Clapton tone control
Posted: Sun Mar 11, 2012 8:22 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Thu Dec 31, 2009 10:34 pm
Posts: 10760
Location: Athens, Greece
The mid-boost pot controls the amount of gain.

If the gain is cranked up to 25dB, the volume is also increased.


Top
Profile
Post subject: Re: 2010 CS LTD Clapton tone control
Posted: Mon Mar 12, 2012 9:59 am
Offline
Roadie
Roadie
User avatar

Joined: Thu Nov 19, 2009 5:08 am
Posts: 263
bluzdawg wrote:
I know I have the mid-boost TBX control on my CS Clapton. But an instructor told me the signature Clapton's come with the Vol control wired to kick in a boost between 8-10. I ca't seem to tell cause it's so frigin loud :-) Can anyone confirm this?


YES, there is a volume boost in there. Though this is nowhere advertised by Fender, the output of a Clapton Strat (i.e. without using the active mid boost) is louder than that of a passive guitar with the same pickups.

Don't know how large the difference is with the noiseless pups. With the old Lace Sensors the volume difference was quite substantial. At volume 8 a Clapton would already be as loud as a Strat Plus with its volume on 10.


Top
Profile
Post subject: Re: 2010 CS LTD Clapton tone control
Posted: Mon Mar 12, 2012 12:00 pm
Offline
Amateur
Amateur

Joined: Sat Oct 03, 2009 10:49 am
Posts: 126
Location: Northern Calif
Thank you!


Top
Profile
Post subject: Re: 2010 CS LTD Clapton tone control
Posted: Mon Mar 12, 2012 2:18 pm
Offline
Rock Star
Rock Star

Joined: Mon Apr 05, 2010 2:37 pm
Posts: 8708
Location: Natural Bridge, Virginia
Robert R. wrote:
bluzdawg wrote:
I know I have the mid-boost TBX control on my CS Clapton. But an instructor told me the signature Clapton's come with the Vol control wired to kick in a boost between 8-10. I ca't seem to tell cause it's so frigin loud :-) Can anyone confirm this?


YES, there is a volume boost in there. Though this is nowhere advertised by Fender, the output of a Clapton Strat (i.e. without using the active mid boost) is louder than that of a passive guitar with the same pickups.

Don't know how large the difference is with the noiseless pups. With the old Lace Sensors the volume difference was quite substantial. At volume 8 a Clapton would already be as loud as a Strat Plus with its volume on 10.


That's only because the mid-boost preamp is always on. Even turned down all the way the preamp is still in the circuit and will boost the volume somewhat. It cannot be turned completely off. The original design had a switch to disable the preamp if the battery died, but Clapton rejected that configuration.

The original statement was:

"But an instructor told me the signature Clapton's come with the Vol control wired to kick in a boost between 8-10"

Yes, there is a volume increase with the mid-boost turned all the way down, but it is present regardless of the volume control setting. Also keep in mind that on a standard CTS pot with an audio taper (which is what Fender uses) there is a noticable change in volume between 8 and 10 with any guitar pickup, passive or active. This has nothing to do with the mid-boost preamp circuit but is simply a characteristic of a modern day audio taper. In my opinion, the instructor's statement is still false.

_________________
Bill



Top
Profile
Post subject: Re: 2010 CS LTD Clapton tone control
Posted: Sat Mar 24, 2012 11:04 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Fri Jul 13, 2007 1:10 pm
Posts: 13467
Location: Palm Beach County FL
Brings back memories of an old thread, about four years ago, when one of the members was trying to verify the tone pot specs in the guitar in that he was in the planning stages to order one. We hadn't been told yet that only the Masterbuilt guitar carried a conventional tone control, yet the specs on the Custom Shop Artist Series guitar also claimed that. It took a long time to get that one straight.

_________________
"Another day in paradise!"


Top
Profile
Post subject: Re: 2010 CS LTD Clapton tone control
Posted: Mon Mar 26, 2012 5:59 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Thu Dec 31, 2009 10:34 pm
Posts: 10760
Location: Athens, Greece
Clapton wanted to get rid of the TBX because he was apparently not satisfied from the muffled tone he got from the VNs. But he agreed to retain the TBX for the regular and teambuild artist versions of his personal stage guitars.



Top
Profile
Post subject: Re: 2010 CS LTD Clapton tone control
Posted: Tue Mar 27, 2012 12:58 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Fri Jul 13, 2007 1:10 pm
Posts: 13467
Location: Palm Beach County FL
That was likely done to maintain the integrity of the Masterbuilt instrument. :idea:

_________________
"Another day in paradise!"


Top
Profile
Post subject: Re: 2010 CS LTD Clapton tone control
Posted: Tue Mar 27, 2012 1:43 am
Offline
Amateur
Amateur

Joined: Sat Oct 03, 2009 10:49 am
Posts: 126
Location: Northern Calif
The question I had concerning my Vol, was on a CS LTD 2010 Grey. They only made those in two colors sold only in the US for the 2010 tour. I doubt they would be any different than the Masterbuilt. In fact I was told you could not get this LTD edition as a Masterbuilt. But then again, I was told you can pretty much get anything Masterbuilt if you want to pay for it 8)


Top
Profile
Post subject: Re: 2010 CS LTD Clapton tone control
Posted: Tue Mar 27, 2012 10:36 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Thu Dec 31, 2009 10:34 pm
Posts: 10760
Location: Athens, Greece
Both EC LTD signatures were offered in team and masterbuild versions.
