Post subject: Champion 600 with 12" speaker?
Posted: Fri Jan 18, 2013 7:36 pm
Offline
Aspiring Musician
Aspiring Musician

Joined: Fri Mar 16, 2012 12:49 pm
Posts: 838
They say that a little knowledge can be a dangerous thing :shock: so before doing anything I may regret, I thought I'd ask.

My potentially dangerous "little knowledge" comes from the printed manuals:
  • Champion 600 <> 6" speaker <> 4-ohm minimum
  • Vibro Champ XD <> 8" speaker <> 4-ohm
  • HRD <> 12" speaker <> 4-ohm or 8-ohm

If my understanding is correct, then it's possible to hook up the Champion 600 with the the 8" speaker of the VCXD as well as the 12" speaker of the HRD. Is it as easy at is sounds or is there much more to the story? If there's a way to do this I would really like to hear the little Champion 600 with a bigger speaker.

Thanks and Cheers!
BM

_________________
This is the Blues. Are you listening?


Top
Profile
Fender Play Winter Sale 2020
Post subject: Re: Champion 600 with 12" speaker?
Posted: Fri Jan 18, 2013 8:24 pm
Offline
Rock Icon
Rock Icon
User avatar

Joined: Tue Jun 29, 2010 1:20 pm
Posts: 9640
Location: Indiana
Yes, you can use either the 4 ohm or 8 ohm speaker with the C600. Just unplug the speaker from the C600, unplug the speaker from the other amp, and plug that speaker into the C600 speaker jack. The C600 sounds great using an ext cab, 12" - 8 ohm.

_________________
---> "The amp should be SWITCHED OFF AND UNPLUGGED before you do this!" <---

Por favor, disculpe mi español, no se llega a la práctica con mucha frecuencia.


Top
Profile
Post subject: Re: Champion 600 with 12" speaker?
Posted: Fri Jan 18, 2013 9:34 pm
Offline
Rock Star
Rock Star

Joined: Mon Apr 05, 2010 2:37 pm
Posts: 8708
Location: Natural Bridge, Virginia
I run my 5F1 modded C600 through an open back cab with an 8 ohm Celestion G12P-80. Sounds fantastic. :D

_________________
Bill



Top
Profile
Post subject: Re: Champion 600 with 12" speaker?
Posted: Sat Jan 19, 2013 6:55 am
Offline
Aspiring Musician
Aspiring Musician

Joined: Fri Mar 16, 2012 12:49 pm
Posts: 838
Thanks for the replies, guys!
shimmilou wrote:
Yes, you can use either the 4 ohm or 8 ohm speaker with the C600. Just unplug the speaker from the C600, unplug the speaker from the other amp, and plug that speaker into the C600 speaker jack. The C600 sounds great using an ext cab, 12" - 8 ohm.
There is enough excess speaker cable in my VCXD such that I can place the Champ onto of it then plug & play. However the same is not true of the speaker cable in the HRD which is just long enough to reach its intended destination.

I suppose I could cut the HRD speaker cable and solder in more speaker wire but I would prefer to leave the HRD speaker cable untouched. Would a cable with 1/4" female on one end and 1/4" male TS connector on the other be the way to go?

Thanks & Cheers!
BM

_________________
This is the Blues. Are you listening?


Top
Profile
Post subject: Re: Champion 600 with 12" speaker?
Posted: Sat Jan 19, 2013 7:43 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Wed Mar 31, 2010 12:48 am
Posts: 26417
Location: Tombstone Territory
Bluer Monkey wrote:
Would a cable with 1/4" female on one end and 1/4" male TS connector on the other be the way to go?


That's how the pro's do it.

Arjay

_________________
"Here's why reliability is job one: A great sounding amp that breaks down goes from being a favorite piece of gear to a useless piece of crap in less time than it takes to read this sentence." -- BRUCE ZINKY


Top
Profile
Post subject: Re: Champion 600 with 12" speaker?
Posted: Sat Jan 19, 2013 8:48 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Tue Jun 29, 2010 1:20 pm
Posts: 9640
Location: Indiana
Since the foot switch cable for the HRDlx appears to be zip cord, more like speaker cable, I cut the foot switch cable in two and crimped connectors on, so now I have two speaker cables with phone plugs already on the ends. On the HRDlx, an instrument cable works fine for the foot switch. I did this to test the HRDlx with other amps speakers, just as you want to do with the C600.

_________________
---> "The amp should be SWITCHED OFF AND UNPLUGGED before you do this!" <---

Por favor, disculpe mi español, no se llega a la práctica con mucha frecuencia.


Top
Profile
Post subject: Re: Champion 600 with 12" speaker?
Posted: Sat Jan 19, 2013 8:53 am
Offline
Aspiring Musician
Aspiring Musician

Joined: Fri Mar 16, 2012 12:49 pm
Posts: 838
shimmilou wrote:
Since the foot switch cable for the HRDlx appears to be zip cord, more like speaker cable, I cut the foot switch cable in two and crimped connectors on, so now I have two speaker cables with phone plugs already on the ends. On the HRDlx, an instrument cable works fine for the foot switch. I did this to test the HRDlx with other amps speakers, just as you want to do with the C600.
I was about to ask what gauge speaker wire to use but your suggestion of using the foot switch cable makes things even easier. Thanks Shimmilou :!:

Cheers!
BM

_________________
This is the Blues. Are you listening?


Top
Profile
Post subject: Re: Champion 600 with 12" speaker?
Posted: Sun Jan 20, 2013 2:04 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Wed Mar 31, 2010 12:48 am
Posts: 26417
Location: Tombstone Territory
shimmilou wrote:
The C600 sounds great using an ext cab, 12" - 8 ohm.


+1!

I frequently play this 12-watt Princeton through a pair of twelves......


A speaker system maximized for efficiency is a great way to put "long pants" on a small amp so it can compete in the big leagues.

Arjay

_________________
"Here's why reliability is job one: A great sounding amp that breaks down goes from being a favorite piece of gear to a useless piece of crap in less time than it takes to read this sentence." -- BRUCE ZINKY


Top
Profile
Post subject: Re: Champion 600 with 12" speaker?
Posted: Sun Jan 20, 2013 7:09 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Tue Jun 29, 2010 1:20 pm
Posts: 9640
Location: Indiana
Sweet! Love that head. :D

It is amazing how much sound that you can get from low-wattage amps. My 100 watt amps, and my friends' 100 watt amps get very little use these days. When I jam with friends (non-professionally), we mainly use a BJr and a Tiny Terror (on 7 watt setting), or some of our other 15 watt or less amps, and even then we rarely turn the volume over 5. Quality over quantity. 8)

_________________
---> "The amp should be SWITCHED OFF AND UNPLUGGED before you do this!" <---

Por favor, disculpe mi español, no se llega a la práctica con mucha frecuencia.


Top
Profile
Post subject: Re: Champion 600 with 12" speaker?
Posted: Sun Jan 20, 2013 8:56 am
Offline
Aspiring Musician
Aspiring Musician

Joined: Fri Mar 16, 2012 12:49 pm
Posts: 838
Holy sonic revelation, Batman!
    Shimmilou, Bluesky, and Arjay were right :!:

First I tried the C600 with the 8" VCHD speaker and noticed a significant and dramatic improvement. In fact I think I like my C600 through the VCXD 8" speaker more than I like my VCXD through the same speaker.

When I hooked the little guy up the the HRD speaker, it blew me away and for a second I was tempted to get a cab and use the C600 as a head. Then it occured to me that the speaker is just one part of the package. The other part is all the mods in Bluesky's Modded Champion 600 thread which is at present - and in the foreseeable future - beyond my ability.

However, if there were some "magical" Kung-Fu to eliminate the hiss, the hum, and add reverb, then I would certainly go for the cab. :lol:

Cheers!
BM

_________________
This is the Blues. Are you listening?


Top
Profile
