Post subject: Re: DRRI background reverb
Posted: Thu Jan 03, 2013 4:50 pm
Offline
Hobbyist
Hobbyist

Joined: Sat Mar 06, 2010 3:32 am
Posts: 27
I'm afraid that's not possible as one of the resistor ends gets cut. I've done the mod perfectly now, the solder joints a strong and shinny. It's not the mod, don't know what it is.


Top
Profile
Fender Play Winter Sale 2020
Post subject: Re: DRRI background reverb
Posted: Thu Jan 03, 2013 5:26 pm
Offline
Rock Icon
Rock Icon
User avatar

Joined: Tue Jun 29, 2010 1:20 pm
Posts: 9640
Location: Indiana
It is possible to solder the snipped resistor, and you can't definitively know that it isn't the mod unless you verify as suggested. BTW, it's shiny.

_________________
---> "The amp should be SWITCHED OFF AND UNPLUGGED before you do this!" <---

Por favor, disculpe mi español, no se llega a la práctica con mucha frecuencia.


Top
Profile
Post subject: Re: DRRI background reverb
Posted: Fri Jan 04, 2013 3:33 am
Offline
Hobbyist
Hobbyist

Joined: Sat Mar 06, 2010 3:32 am
Posts: 27
True, I could but why would it be the mod if it appears as though the mod is working? Another question, what part of the mod did I possibly do wrong that could cause reverb to leak into the dry signal? I mean, it's a really simply mod, there's nothing to go wrong. If one of the resistors got too hot would that cause it? The reverb and vibrato are added to channel 1, I don't see how the mod would affect the dry signal.


Top
Profile
Post subject: Re: DRRI background reverb
Posted: Fri Jan 04, 2013 10:08 am
Offline
Hobbyist
Hobbyist

Joined: Sun Apr 29, 2012 9:11 pm
Posts: 58
Could it possibly be a microphonic tube?


Top
Profile
Post subject: Re: DRRI background reverb
Posted: Fri Jan 04, 2013 1:20 pm
Offline
Rock Icon
Rock Icon
User avatar

Joined: Wed Mar 31, 2010 12:48 am
Posts: 26417
Location: Tombstone Territory
twotone57 wrote:
Could it possibly be a microphonic tube?


I wouldn't rule it out at this point.

Arjay

_________________
"Here's why reliability is job one: A great sounding amp that breaks down goes from being a favorite piece of gear to a useless piece of crap in less time than it takes to read this sentence." -- BRUCE ZINKY


Top
Profile
Post subject: Re: DRRI background reverb
Posted: Fri Jan 04, 2013 6:46 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Sat Jul 03, 2010 2:18 pm
Posts: 6544
In amps with circuit boards the board, itself, can become interactive and microphonic. A LITTLE bit of silicone sealer between heavy components or between these components and the board can help this issue.

Are you sure the "reverb" artifact is the same, in all parts of a room of in other rooms? I've rule this out, first before digging into the amp's cicruitry.

Alos, too much gain may lead to microphony or feedback issues. May want to try a good lower gain tube in the input section (like a quiet 5751), too.

Good luck!



Top
Profile
Post subject: Re: DRRI background reverb
Posted: Sat Jan 05, 2013 8:12 am
Offline
Hobbyist
Hobbyist

Joined: Sat Mar 06, 2010 3:32 am
Posts: 27
Thanks for your replies. I put a 12AU7 in the reverb position and it seems to have got rid of the reverb. I have a feeling the 12AU7 is noisier than the 12AX7, is that normal?

Am glad I redid the mod anyway because it was always in the back of my mind what a crappy job I did of it. :lol:


Top
Profile
Post subject: Re: DRRI background reverb
Posted: Sat Jan 05, 2013 9:18 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Wed Mar 31, 2010 12:48 am
Posts: 26417
Location: Tombstone Territory
There are two tubes delegated to the reverb circuit (V3 and V4). In which socket did you install the 12AU7?

Arjay

_________________
"Here's why reliability is job one: A great sounding amp that breaks down goes from being a favorite piece of gear to a useless piece of crap in less time than it takes to read this sentence." -- BRUCE ZINKY


Top
Profile
Post subject: Re: DRRI background reverb
Posted: Sat Jan 05, 2013 9:33 am
Offline
Hobbyist
Hobbyist

Joined: Sat Mar 06, 2010 3:32 am
Posts: 27
I put it in 3, should I put a 12AU7 in 4 as well? Am not 100% sure but the 12AU7 seems to add more noise. I definitely need to use higher numbers to get the same level of reverb.


Top
Profile
Post subject: Re: DRRI background reverb
Posted: Sat Jan 05, 2013 9:48 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Wed Mar 31, 2010 12:48 am
Posts: 26417
Location: Tombstone Territory
Try a 12AY7 there -- the higher amplification factor may lessen the noise and give you more usable reverb effect.

Arjay

_________________
"Here's why reliability is job one: A great sounding amp that breaks down goes from being a favorite piece of gear to a useless piece of crap in less time than it takes to read this sentence." -- BRUCE ZINKY


Top
Profile
