Post subject: loose contacts on backside of preamp socket causing static..
Posted: Thu Mar 22, 2012 10:21 am
Offline
Roadie
Roadie
User avatar

Joined: Thu Jul 10, 2008 8:30 am
Posts: 220
Location: DOWN south
well i thought at first it was the tube (V1/12AX7/supersonic 22)
but when i wiggled the tube gently, i got all kind of hiss/static but NO pops
so i think the connection is not that bad but def needs to be fixed.
Pulled the chassis and re-tensioned the socket based on the method of inserting a very
small jeweler screwdriver into each hole and turning gently.
That seemed to help but I still have some play when i touch the actual contact tabs (where the wires are soldered on back of socket)
The tabs on the other sockets are firm - any tricks to fix OR do i have to replace the socket?
This amp was bought new and is only a year old
here is the pic:

_________________


Top
Profile
Fender Play Winter Sale 2020
Post subject: Re: loose contacts on backside of preamp socket causing stat
Posted: Thu Mar 22, 2012 10:37 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Tue Jun 29, 2010 1:20 pm
Posts: 9640
Location: Indiana
With the tube removed from the socket, a small amount of play is normal and good for the pins. You want the socket pins to be able to move a little, to be able to line up with the tube pins which can vary from tube to tube. Sometimes, a little too much solder on the terminals can make the pins feel stiff without movement. Two terminals, next to each other, soldered together, will also feel stiffer for those pins.

If the terminals still feel loose with a tube inserted in the socket, the socket pins should be re-tensioned, and if that doesn't work, replace the socket.

Edit:
Check this site for pics and some more tips.

http://billmaudio.com/wp/?page_id=171

_________________
---> "The amp should be SWITCHED OFF AND UNPLUGGED before you do this!" <---

Por favor, disculpe mi español, no se llega a la práctica con mucha frecuencia.


Last edited by shimmilou on Thu Mar 22, 2012 5:43 pm, edited 2 times in total.

Top
Profile
Post subject: Re: loose contacts on backside of preamp socket causing stat
Posted: Thu Mar 22, 2012 1:23 pm
Offline
Roadie
Roadie
User avatar

Joined: Thu Jul 10, 2008 8:30 am
Posts: 220
Location: DOWN south
thanks Shimm~


Top
Profile
Post subject: Re: loose contacts on backside of preamp socket causing stat
Posted: Thu Mar 22, 2012 1:58 pm
Offline
Rock Icon
Rock Icon
User avatar

Joined: Tue Jun 29, 2010 1:20 pm
Posts: 9640
Location: Indiana
Make sure that you get the screwdriver between the socket pin and the wall around the pin, and down into the hole past the flared opening. Best to do each pin in two places at least, once on each side of the split in the socket pin, until you can visually see that the pin hole looks smaller. You don't want to twist too hard, yet you have to use enough force to actually bend the metal back into place, maintaining the round shape.

Edit:
Check this site for pics and some more tips.

http://billmaudio.com/wp/?page_id=171

_________________
---> "The amp should be SWITCHED OFF AND UNPLUGGED before you do this!" <---

Por favor, disculpe mi español, no se llega a la práctica con mucha frecuencia.
