Post subject: Re: Super-Sonic 22 Bias Level
Posted: Fri Feb 25, 2011 8:10 pm
Offline
Roadie
Roadie

Joined: Sun Aug 02, 2009 6:55 pm
Posts: 297
Location: Warren Mi
twirlyboggs wrote:
i guess i am going to put some JJ6V6's and some electro harmonix 12AX7 (3) and 12AT7 (2) one o fthem balanced for the PI - I will post my results when i do....
My Twin i retubed with just all (pre& power amp) Electro-Harmonix & it was an improvement to the GT's that came new when i ordered the amp, except the reverb 12AT7 was a lil on the gainy side, the reverb IF set high would get get a lil fizzy. But I always set it around 2-3 so I did not have an issue. I would also say that the EH made the amp have a lil more gain, but tighter, on the dirty channel. This is my pro-tube Twin~Amp 100W btw.
Is the PI V3?? 12ax7?
On the other hand, on my Champ, when i went from a electro-harmonix 6v6 which came with it to a JJ6v6, the results were awesome! The breakup was less harsh and more warm and just in there if you know what i mean.

So i am kinda back & forth on JJ or EH for the 6v6 pair.


Top
Profile
Fender Play Winter Sale 2020
Post subject: Re: Super-Sonic 22 Bias Level
Posted: Fri Feb 25, 2011 8:20 pm
Offline
Rock Icon
Rock Icon
User avatar

Joined: Tue Jun 29, 2010 1:20 pm
Posts: 9640
Location: Indiana
You put your question in the middle of the quote, so it looked like part of the original post. I didn't see it at first, and wondered why you quoted the post. :lol:

Quote:
Is the PI V3?? 12ax7?

_________________
---> "The amp should be SWITCHED OFF AND UNPLUGGED before you do this!" <---

Por favor, disculpe mi español, no se llega a la práctica con mucha frecuencia.


Top
Profile
Post subject: Re: Super-Sonic 22 Bias Level
Posted: Fri Feb 25, 2011 8:46 pm
Offline
Roadie
Roadie

Joined: Sun Aug 02, 2009 6:55 pm
Posts: 297
Location: Warren Mi
anybody have the tube chart, shows the gain stages and all


Top
Profile
Post subject: Re: Super-Sonic 22 Bias Level
Posted: Sat Feb 26, 2011 12:25 am
Offline
Amateur
Amateur
User avatar

Joined: Wed Jan 26, 2011 12:53 pm
Posts: 112
shimmilou wrote:
You put your question in the middle of the quote, so it looked like part of the original post. I didn't see it at first, and wondered why you quoted the post. :lol:

Quote:
Is the PI V3?? 12ax7?


V5 ist the PI it's a 12AT7, right next to the Powertubes. Mine had GT relabled JJ'S in them (which where rattling), and I like the TUNGSOLs better.... also than the EH's.

I am asking this on this thread also, because I want to find out what the deal with the hiss is:

How loud the hiss on your amps in a real quiet area when no instrument is plugged in and the volume knobs and reverb are completely turned down? Mine is sounding great, but the hiss is really noticable/annoying at home levels. My PRRI in comparance is totally quiet at idle.

Some people also complained about this - and other issues that mine has not - so I want to know if this really is in the design of the amp (like the CVR) or a fault in the unit.

It is not a tube problem. I retubed all slots with low noise and hum tubes (V1 Jan 12Ax7, V2 Tungsol RI V3 TAD 12AT7 balanced V4 EH LPS V5 JAN 12AT7, V6&7: TUNGSOL 6V6) And of course I also rebiased. When I hat the chassis, everything inside looke nice and clean as far as I could tell.

If someone has a real quiet one, I would really appreciate it, if you please let me know!!!!

Thanks!!!!


Top
Profile
Post subject: Re: Super-Sonic 22 Bias Level
Posted: Sat Feb 26, 2011 7:14 am
Offline
Roadie
Roadie

Joined: Sun Aug 02, 2009 6:55 pm
Posts: 297
Location: Warren Mi
mines quiet, could be the transformer maybe


Top
Profile
Post subject: Re: Super-Sonic 22 Bias Level
Posted: Sat Feb 26, 2011 8:15 am
Offline
Amateur
Amateur
User avatar

Joined: Wed Jan 26, 2011 12:53 pm
Posts: 112
ken361 wrote:
mines quiet, could be the transformer maybe


You mean a faulty transformer?
Anyway, I made a video where you can here it...
http://www.youtube.com/watch?v=2cD1H5ujrQk

Thanks,
Reverend


Top
Profile
Post subject: Re: Super-Sonic 22 Bias Level
Posted: Sat Feb 26, 2011 8:24 am
Offline
Roadie
Roadie

Joined: Sun Aug 02, 2009 6:55 pm
Posts: 297
Location: Warren Mi
I hear a hiss on mine on the burn when i turn it up, pretty much any amp I think will do that, but the clean channel is more quiet on mine


Top
Profile
Post subject: Re: Super-Sonic 22 Bias Level
Posted: Sat Feb 26, 2011 8:45 am
Offline
Roadie
Roadie

Joined: Sun Aug 02, 2009 6:55 pm
Posts: 297
Location: Warren Mi
thereverend wrote:
shimmilou wrote:
You put your question in the middle of the quote, so it looked like part of the original post. I didn't see it at first, and wondered why you quoted the post. :lol:

Quote:
Is the PI V3?? 12ax7?


V5 ist the PI it's a 12AT7, right next to the Powertubes. Mine had GT relabled JJ'S in them (which where rattling), and I like the TUNGSOLs better.... also than the EH's.

I am asking this on this thread also, because I want to find out what the deal with the hiss is:

How loud the hiss on your amps in a real quiet area when no instrument is plugged in and the volume knobs and reverb are completely turned down? Mine is sounding great, but the hiss is really noticable/annoying at home levels. My PRRI in comparance is totally quiet at idle.

Some people also complained about this - and other issues that mine has not - so I want to know if this really is in the design of the amp (like the CVR) or a fault in the unit.

It is not a tube problem. I retubed all slots with low noise and hum tubes (V1 Jan 12Ax7, V2 Tungsol RI V3 TAD 12AT7 balanced V4 EH LPS V5 JAN 12AT7, V6&7: TUNGSOL 6V6) And of course I also rebiased. When I hat the chassis, everything inside looke nice and clean as far as I could tell.

If someone has a real quiet one, I would really appreciate it, if you please let me know!!!!

Thanks!!!!

I ordered a Mullard NOS form dougs tubes 35 bucks , sweet tube


Top
Profile
Post subject: Re: Super-Sonic 22 Bias Level
Posted: Sat Feb 26, 2011 8:51 am
Offline
Amateur
Amateur
User avatar

Joined: Wed Jan 26, 2011 12:53 pm
Posts: 112
ken361 wrote:
I hear a hiss on mine on the burn when i turn it up, pretty much any amp I think will do that, but the clean channel is more quiet on mine


I know, but this is not what I mean.
The hiss is there regardless of the volume on the channels...even completely turned down.
And no NOS tube fixed that. It only gets a little better when you change the gain of the tubes.
For example if you put a 12AT7 in V4 instead of a 12Ax7 or a 12Au7 in V5 instead of a 12At7...

If I put a Volume Pedal in the FX LOOP, I can turn down the hiss. So I assume the hiss is created before the FX LOOP....


Top
Profile
Post subject: Re: Super-Sonic 22 Bias Level
Posted: Sat Feb 26, 2011 9:04 am
Offline
Roadie
Roadie

Joined: Sun Aug 02, 2009 6:55 pm
Posts: 297
Location: Warren Mi
thereverend wrote:
ken361 wrote:
I hear a hiss on mine on the burn when i turn it up, pretty much any amp I think will do that, but the clean channel is more quiet on mine


I know, but this is not what I mean.
The hiss is there regardless of the volume on the channels...even completely turned down.
And no NOS tube fixed that. It only gets a little better when you change the gain of the tubes.
For example if you put a 12AT7 in V4 instead of a 12Ax7 or a 12Au7 in V5 instead of a 12At7...

If I put a Volume Pedal in the FX LOOP, I can turn down the hiss. So I assume the hiss is created before the FX LOOP....

that is strange even with the volume down, call fender at all?


Top
Profile
Post subject: Re: Super-Sonic 22 Bias Level
Posted: Sat Feb 26, 2011 9:08 am
Offline
Amateur
Amateur
User avatar

Joined: Wed Jan 26, 2011 12:53 pm
Posts: 112
I think I will contact them on monday...


Top
Profile
Post subject: Re: Super-Sonic 22 Bias Level
Posted: Wed Mar 09, 2011 9:32 am
Offline
Roadie
Roadie
User avatar

Joined: Thu Jul 10, 2008 8:30 am
Posts: 220
Location: DOWN south
well I just biased my Super-Sonic 22 (stock power tubes- Groove Tubes 6V6 "6's : white")
the amp is only 1 month old - well 2 months from the stamp from the factory
SO, the bias was set to 32mV !
I lowered it to 24mV - sounds good, breaks up a lil different on the clean channel now, i like it.
TP40(D35) was at 32 and TP41(D36) at 31 !
My plate voltage, TP43(D38) was 413 VDC.

thought i would post this as any info. MANY THANKS to everyone in this post!!!!!!

_________________


Top
Profile
Post subject: Re: Super-Sonic 22 Bias Level
Posted: Wed Mar 09, 2011 9:54 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Tue Jun 29, 2010 1:20 pm
Posts: 9640
Location: Indiana
Awesome twirlyboggs! Every time someone properly sets the bias on their Fender amp, an Angel rings a bell.....or something like that. :lol: Good job, congrats. :)

_________________
---> "The amp should be SWITCHED OFF AND UNPLUGGED before you do this!" <---

Por favor, disculpe mi español, no se llega a la práctica con mucha frecuencia.


Top
Profile
Post subject: Re: Super-Sonic 22 Bias Level
Posted: Wed Mar 09, 2011 10:55 am
Offline
Roadie
Roadie
User avatar

Joined: Thu Jul 10, 2008 8:30 am
Posts: 220
Location: DOWN south

PLATE VOLTS AT - D38 - 415 VOLTS, MINE AT 413

_________________


Top
Profile
Post subject: Re: Super-Sonic 22 Bias Level
Posted: Wed Mar 09, 2011 10:57 am
Offline
Roadie
Roadie
User avatar

Joined: Thu Jul 10, 2008 8:30 am
Posts: 220
Location: DOWN south
TEST POINTS FOR BIAS - D35 & D36

_________________


Top
