Post subject: Shorting Jacks on a new 5E3.
Posted: Sun Jul 03, 2016 11:45 am
Offline
Professional Musician
Professional Musician
User avatar

Joined: Fri Nov 09, 2007 7:46 am
Posts: 1019
Location: State of Confusion
I have a <1 yr. old Fender '57 Deluxe Head Clone.
Periodically, I get a nasty hum which I've traced to poor contact (due to oxidation) of the unused shorting jack inputs (4) (where the shorting jack arm contacts the tip arm). If I clean the points of contact, all is well (no hum) for a period....maybe 4-6 weeks, then it recurs and I have to repeat the process. It's a PITA.

Could a tiny dab of a contact grease on the "points" eliminate the recurrence (or at least make it much less frequent)? OR would this likely cause other problem(s)? If this would work, what product is recommended?

Thanks in advance for your personal experience.

_________________
The quintessential sound of 60/70's R&R:
Fender Tube Amps
Gibson Guitars


Top
Profile
Fender Play Winter Sale 2020
Post subject: Re: Shorting Jacks on a new 5E3.
Posted: Sun Jul 03, 2016 2:12 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Sat Jul 03, 2010 2:18 pm
Posts: 6544
Clean & adjust the contact points, so the faces have the most contact.

I like crocus or fine emery cloth to clean contact faces. Then, a small needle-nose plier to tighten & adjust the points for parallel contact. Kinda like cleaning and fitting old school ignition points, in cars.

Lube the contacts with Deoxit D5 or GN5. Good luck!


Top
Profile
Post subject: Re: Shorting Jacks on a new 5E3.
Posted: Sun Jul 03, 2016 3:34 pm
Offline
Rock Icon
Rock Icon
User avatar

Joined: Wed Mar 31, 2010 12:48 am
Posts: 26417
Location: Tombstone Territory
BMW2002Ti wrote:
Clean & adjust the contact points, so the faces have the most contact.

I like crocus or fine emery cloth to clean contact faces. Then, a small needle-nose plier to tighten & adjust the points for parallel contact. Kinda like cleaning and fitting old school ignition points, in cars.

Lube the contacts with Deoxit D5 or GN5. Good luck!


+1 in all respects.

Humid environments frequently cause issues such as these. A room dehumidifier may help. If that's impractical, toss a couple of desiccant bags in the bottom of the amp's cabinet. That might work.

Arjay

_________________
"Here's why reliability is job one: A great sounding amp that breaks down goes from being a favorite piece of gear to a useless piece of crap in less time than it takes to read this sentence." -- BRUCE ZINKY


Top
Profile
Post subject: Re: Shorting Jacks on a new 5E3.
Posted: Sun Jul 03, 2016 3:43 pm
Offline
Rock Icon
Rock Icon
User avatar

Joined: Fri Feb 05, 2010 4:31 am
Posts: 14049
Location: Province de Québec, Canada
BMW2002Ti wrote:
Clean & adjust the contact points, so the faces have the most contact.

I like crocus or fine emery cloth to clean contact faces. Then, a small needle-nose plier to tighten & adjust the points for parallel contact. Kinda like cleaning and fitting old school ignition points, in cars.

Lube the contacts with Deoxit D5 or GN5. Good luck!


I sometime see this do not last or do not work. I should replace the jack.


Top
Profile
Post subject: Re: Shorting Jacks on a new 5E3.
Posted: Sun Jul 03, 2016 4:29 pm
Offline
Professional Musician
Professional Musician
User avatar

Joined: Fri Nov 09, 2007 7:46 am
Posts: 1019
Location: State of Confusion
Have been doing the cleaning with CRC and it does clean, but doesn't last as long as I'd like (as mentioned 4-6 weeks). Does Deoxit D5 have a residual that will extend the 'fix' before recurrence? Or is there another product to add after cleaning.

Seems as if cleaning/deoxidizing isn't my problem, but extending the period between cleaning is. The area that I live is not excessively humid.

_________________
The quintessential sound of 60/70's R&R:
Fender Tube Amps
Gibson Guitars


Top
Profile
Post subject: Re: Shorting Jacks on a new 5E3.
Posted: Sun Jul 03, 2016 10:42 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Sat Jul 03, 2010 2:18 pm
Posts: 6544
IM4Tone, yes CAIG Deoxit cleans & lubricants. Use D100 or GN100 brush applicant for the contacts. It'll last longer and be less messy.

1.) 7 ml bottle will last you forever. Deoxit is great for all connectors. Like ones in cars, other home electronics.

https://www.amazon.com/DeoxITGOLD-Liqui ... caig+gn100

2.) If you still have issues, go for a Switchcraft jack.

https://www.tubesandmore.com/products/W-SC-L12A

3.) Or make a DIY shorted 1/4-inch plug. Get a plug and solder a short lead between center tang and outer ground tang. Plug this into jack --- and it will short-out the jack.


Top
Profile
Post subject: Re: Shorting Jacks on a new 5E3.
Posted: Mon Jul 04, 2016 1:54 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Fri Feb 05, 2010 4:31 am
Posts: 14049
Location: Province de Québec, Canada
IM4Tone wrote:


Seems as if cleaning/deoxidizing isn't my problem, but extending the period between cleaning is. The area that I live is not excessively humid.


Contact loose is protecting coat and anything you"ll try will not last longer. You need new jack.
You must never file a electrical contact except with a burnishing tools or a dollar paper. Using something more abrasive will ruin the contact protective coat.


Top
Profile
Post subject: Re: Shorting Jacks on a new 5E3.
Posted: Mon Jul 04, 2016 2:05 am
Offline
Rock Star
Rock Star
User avatar

Joined: Sat Jul 03, 2010 2:18 pm
Posts: 6544
Stratele, I agree... not to touch contact surfaces, if the surfaces are intact. But, often they are not. They get oxidized to the degree that it the total metal-metal contact area is affected. Sometimes, there is electrolysis between them.

The only way to improve the action is to clean the two areas, so you get as much clean, un-oxidized surface area contact as possible.

It's the only way to save some of the more vintage jacks and switches. As the newly made items are not built to same electrical & mechanical standards as the original ones. And few NOS are available.

Crocus cloth or fine emery is ok for this work. Use a fine touch. He maybe able to save the jack without having to pull it and solder in a new one.

:)


Top
Profile
Post subject: Re: Shorting Jacks on a new 5E3.
Posted: Mon Jul 04, 2016 2:12 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Fri Feb 05, 2010 4:31 am
Posts: 14049
Location: Province de Québec, Canada
Switchraft jack are same quality as vintage jack.
I see some brand new jack with defective contact.


Top
Profile
Post subject: Re: Shorting Jacks on a new 5E3.
Posted: Mon Jul 04, 2016 4:21 pm
Offline
Professional Musician
Professional Musician
User avatar

Joined: Fri Nov 09, 2007 7:46 am
Posts: 1019
Location: State of Confusion
Thanks to all who responded!

No one really answered my original question about conductive grease..."Could a tiny dab of a contact grease on the "points" eliminate the recurrence (or at least make it much less frequent)? OR would this likely cause other problem(s)? If this would work, what product is recommended?", but gave other advice. I will get some of the Deoxit D5 since it has a residual lubricant in hopes that the points remain conductive much longer

For stratele52, this is not a vintage amp and is less than a year old. The oxidation is not difficult to remove and I've never had to resort to abrasives. That would be my last resort, as I do realize that this would eventually remove the plating and render the area more susceptible to further corrosion. FWIW, the brand of jack is Neutrik. Don't know if it's inferior, equal to, or better than Switchcraft, but in the few instances I've replaced jacks, it's always been with Switchcraft and probably will be for any future needs. I'm convinced that, at this time, jack replacement isn't necessary.

So when and if the poor ground returns (if the past is an indicator- in 4 to 6 weeks), I'll Deoxit and see how long that lasts.

Thanks again,
IM4Tone

_________________
The quintessential sound of 60/70's R&R:
Fender Tube Amps
Gibson Guitars


Top
Profile
Post subject: Re: Shorting Jacks on a new 5E3.
Posted: Mon Jul 04, 2016 5:44 pm
Offline
Rock Icon
Rock Icon
User avatar

Joined: Wed Mar 31, 2010 12:48 am
Posts: 26417
Location: Tombstone Territory
I couldn't find a single Neutrik product in this piece of equipment......


It was, however, loaded with Switchcraft stuff.

:wink:

Arjay

_________________
"Here's why reliability is job one: A great sounding amp that breaks down goes from being a favorite piece of gear to a useless piece of crap in less time than it takes to read this sentence." -- BRUCE ZINKY


Top
Profile
Post subject: Re: Shorting Jacks on a new 5E3.
Posted: Mon Jul 04, 2016 7:41 pm
Offline
Aspiring Musician
Aspiring Musician
User avatar

Joined: Sat Mar 20, 2010 2:30 pm
Posts: 792
Location: A Land Downunder
Is the CRC you are using just a cleaner or the "Cleaner/Lubricant" version which has a residual protection/lubricant component ?

I've used this one which is very good.
http://www.crcindustries.com.au/product ... -lubricant

If that fails, replace the jack with a Switchcraft and it will probably never happen again, or at least it will eliminate the mechanics of the jack as an issue, but a poor physical contact is the usual culprit that then leads to the electrical problem.


Top
Profile
Post subject: Re: Shorting Jacks on a new 5E3.
Posted: Mon Jul 04, 2016 8:26 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Sat Jul 03, 2010 2:18 pm
Posts: 6544
Retroverbial wrote:
I couldn't find a single Neutrik product in this piece of equipment......

It was, however, loaded with Switchcraft stuff.

:wink:

Arjay


Arjay,

Mil spec'ed Erection Amplifier (pre-Viagra) --- from a B47. 5751 tubes under those shields. :)





Top
Profile
Post subject: Re: Shorting Jacks on a new 5E3.
Posted: Mon Jul 04, 2016 8:44 pm
Offline
Professional Musician
Professional Musician
User avatar

Joined: Fri Nov 09, 2007 7:46 am
Posts: 1019
Location: State of Confusion
No457 Snowy wrote:
Is the CRC you are using just a cleaner or the "Cleaner/Lubricant" version which has a residual protection/lubricant component ? .................

I believe it is just the cleaner.
Thanks

_________________
The quintessential sound of 60/70's R&R:
Fender Tube Amps
Gibson Guitars


Top
Profile
Post subject: Re: Shorting Jacks on a new 5E3.
Posted: Tue Jul 05, 2016 12:36 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Fri Feb 05, 2010 4:31 am
Posts: 14049
Location: Province de Québec, Canada
IM4Tone wrote:
Thanks to all who responded!

No one really answered my original question about conductive grease..."Could a tiny dab of a contact grease on the "points" eliminate the recurrence (or at least make it much less frequent)? OR would this likely cause other problem(s)? If this would work, what product is recommended?", but gave other advice. I will get some of the Deoxit D5 since it has a residual lubricant in hopes that the points remain conductive much longer

For stratele52, this is not a vintage amp and is less than a year old. The oxidation is not difficult to remove and I've never had to resort to abrasives. That would be my last resort, as I do realize that this would eventually remove the plating and render the area more susceptible to further corrosion. FWIW, the brand of jack is Neutrik. Don't know if it's inferior, equal to, or better than Switchcraft, but in the few instances I've replaced jacks, it's always been with Switchcraft and probably will be for any future needs. I'm convinced that, at this time, jack replacement isn't necessary.

So when and if the poor ground returns (if the past is an indicator- in 4 to 6 weeks), I'll Deoxit and see how long that lasts.

Thanks again,
IM4Tone


No answer about conductive because ;
1- Who knew this product ?
2- Who use it ?
3- Because conductive grease may not work very well. Jack could be short all the time.

I have conductive grease at home, at $14 a tube is more expensive than few Switchraft jacks and less reliable.

I can't find this jack in Neutrik product. Where and how do you see it is a Neutrik ?
