Post subject: Resources to learn about working on my vintage Fender Amp?
Posted: Mon Oct 06, 2014 12:33 am
Offline
Hobbyist
Hobbyist

Joined: Sat Sep 20, 2014 7:08 pm
Posts: 21
Hi everyone,

I've had a late 60's/early 70's Fender Princeton Reverb ever since I was 13 years old in 1982 or so, and it has yet to be serviced while I've owned it.

I looked in the back, and it seems to be mostly RCA and a few Sylvania tubes, and 1 or 2 I couldn't make out. The largest tube on the left is a little loose in the socket.

It hasn't been turned on in a while, as I've been focusing more on bass in the last few years. Last I remember, it functioned ok, with maybe a little hum, and some crackling in the pots.

I have recently gained a huge interest in electronics, and want to learn more about how to work on them. I'd like to know what I should study to do basic work on vintage amps like this one and possibly others.

Where should I look?

Here are some obligatory photos! :lol:

Cool "vintage" style photo!

Speaker

Sticker code on speaker

Back, right side

Back, more right side

Back, left side

Standard view of front-

Unfortunately, some moron I let use my amp many years ago broke the knob off the intensity control- luckily, I think I still have the knob somewhere, and I never used that effect anyway. :roll:


Top
Profile
Fender Play Winter Sale 2020
Post subject: Re: Resources to learn about working on my vintage Fender Am
Posted: Mon Oct 06, 2014 1:06 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Fri Feb 05, 2010 4:31 am
Posts: 14049
Location: Province de Québec, Canada
Parts for these amps are easy avalaible , like knob.....
Great store here ;

https://www.tubesandmore.com/products/P-K314
__________________________________________________
Books to learn ;

Must have , all of them ;

http://www.kendrick-amplifiers.com/mm5/ ... y_Code=054

This one is a must too ;

http://www.amazon.com/Tube-Amp-Book-Rev ... guitar+amp


Beware ; tubes amps have lethal voltage and can kill you
