Post subject: Re: Blackface Deluxe ("Non-Reverb") - Logo question?
Posted: Wed Oct 09, 2013 5:32 am
Offline
Rock Star
Rock Star
User avatar

Joined: Sat Jul 03, 2010 2:18 pm
Posts: 6544
22mfd/500VDC caps will work fine in your amp. Didn't your tech bias the amp? Should always be done after tube and/or power filter cap change-outs. It does sound like the amp is running a bit "cold."

The easiest way to bias a Deluxe is to get a bias adapter than fits between the socket and tube. You can then adjust bias without pulling the chassis. Some bias adapters have capabilty of reading the plate voltage, too. You need this value to accurately adjust the tubes to proper idle wattage.


Top
Profile
Fender Play Winter Sale 2020
Post subject: Re: Blackface Deluxe ("Non-Reverb") - Logo question?
Posted: Wed Oct 09, 2013 8:41 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Wed Mar 31, 2010 12:48 am
Posts: 26417
Location: Tombstone Territory
simian wrote:
One last question - my repair guy replaced the caps (as in, the 4 under the chassis, in the "can" with 22uF caps, although I've noticed that the original values should be 16uF. Is this a big enough margin to affect the tone? I've heard of the effects of "over-filtering" before, but obviously I dont want to assume that I know more than an experienced tech.
Thanks!,


Higher values in the filter-cap section often produce the result of tightening up an amp's bass response. In concert with a slightly cold idle bias, it could be the cause of the perceived "thinness". The cabinet is adequately sized for the speaker so that is not an issue.

Arjay

_________________
"Here's why reliability is job one: A great sounding amp that breaks down goes from being a favorite piece of gear to a useless piece of crap in less time than it takes to read this sentence." -- BRUCE ZINKY


Top
Profile
Post subject: Re: Blackface Deluxe ("Non-Reverb") - Logo question?
Posted: Wed Oct 09, 2013 3:07 pm
Offline
Hobbyist
Hobbyist
User avatar

Joined: Mon Oct 13, 2008 2:15 pm
Posts: 54
BMW2002ti - thanks for the advice, I'm going to order a Bias Adapter. The tech did bias it, but I can't say for sure that his settings match what I'm looking for, also I'd like to try out some other tubes, so I presume I'll need to reset bias again at some point.

Arjay - thanks (again!) - I may at some stage consider returning the caps to their original values, actually my tech used the phrase "tightening up" when describing the work he'd done. I'd be interested to know if people had any thoughts on whether it's better to go "vintage-correct" in this regard?

While we're here, does anyone have any particular power tube suggestions for this amp?


Top
Profile
Post subject: Re: Blackface Deluxe ("Non-Reverb") - Logo question?
Posted: Wed Oct 09, 2013 3:48 pm
Offline
Hobbyist
Hobbyist
User avatar

Joined: Mon Oct 13, 2008 2:15 pm
Posts: 54
...Sorry, also forgot to ask, can anyone tell me the recommended settings when biasing tubes in this circuit? Looking for info on the Deluxe is like like looking for a needle in a pile of webpages devoted to Deluxe Reverbs! :lol:


Top
Profile
Post subject: Re: Blackface Deluxe ("Non-Reverb") - Logo question?
Posted: Wed Oct 09, 2013 4:07 pm
Offline
Rock Icon
Rock Icon
User avatar

Joined: Wed Mar 31, 2010 12:48 am
Posts: 26417
Location: Tombstone Territory
It's been decades since I owned a non-verb AB763 Deluxe Amp but I'll pass on what I can. The schematic shows 410VDC at the plates (slightly lower than the reverb-equipped edition). A good base-line for the idle bias is around 19.5mA. I run the output bottles in all three of my DR's at 21mA. I would not push 6V6GTA's beyond 23mA in any scenario to avoid the risk of red-plating and damage. Your ears and your wallet will determine which brand of tube works best. I prefer US-made NOS glass but there are several contemporary tubes available that will work well.

Arjay

_________________
"Here's why reliability is job one: A great sounding amp that breaks down goes from being a favorite piece of gear to a useless piece of crap in less time than it takes to read this sentence." -- BRUCE ZINKY


Top
Profile
Post subject: Re: Blackface Deluxe ("Non-Reverb") - Logo question?
Posted: Thu Oct 10, 2013 2:15 am
Offline
Hobbyist
Hobbyist
User avatar

Joined: Mon Oct 13, 2008 2:15 pm
Posts: 54
Great, thanks so much, I'm gonna do some studying while I'm waiting for that bias adapter.


Top
Profile
Post subject: Re: Blackface Deluxe ("Non-Reverb") - Logo question?
Posted: Thu Oct 10, 2013 9:29 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Wed Mar 31, 2010 12:48 am
Posts: 26417
Location: Tombstone Territory
What speaker for this amp did you ultimately decide on?

Arjay

_________________
"Here's why reliability is job one: A great sounding amp that breaks down goes from being a favorite piece of gear to a useless piece of crap in less time than it takes to read this sentence." -- BRUCE ZINKY


Top
Profile
Post subject: Re: Blackface Deluxe ("Non-Reverb") - Logo question?
Posted: Thu Oct 10, 2013 2:05 pm
Offline
Hobbyist
Hobbyist
User avatar

Joined: Mon Oct 13, 2008 2:15 pm
Posts: 54
I went for the Warehouse G12C, which I already had in my Blues Deluxe. I thought this would be the one, it has a lovely rounded, sparkling tone. Nice thing is, the G12C/S that I bought for the Deluxe has now gone into the Blues Deluxe, and it's perfect, as the BDX is quite bright as it is, so this speaker is a change I'd been considering for a while. Good week!


Top
Profile
Post subject: Re: Blackface Deluxe ("Non-Reverb") - Logo question?
Posted: Thu Oct 10, 2013 2:15 pm
Offline
Aspiring Musician
Aspiring Musician
User avatar

Joined: Sun Apr 14, 2013 4:41 pm
Posts: 764
Location: Sydney. Australia
How would you compare G12C/S and G12C?


Top
Profile
Post subject: Re: Blackface Deluxe ("Non-Reverb") - Logo question?
Posted: Thu Oct 10, 2013 2:44 pm
Offline
Rock Icon
Rock Icon
User avatar

Joined: Wed Mar 31, 2010 12:48 am
Posts: 26417
Location: Tombstone Territory
simian wrote:
I went for the Warehouse G12C, which I already had in my Blues Deluxe. I thought this would be the one, it has a lovely rounded, sparkling tone. Nice thing is, the G12C/S that I bought for the Deluxe has now gone into the Blues Deluxe, and it's perfect, as the BDX is quite bright as it is, so this speaker is a change I'd been considering for a while. Good week!


To the symbiotic benefit of both amps.

Rawk on!

8)

Arjay

_________________
"Here's why reliability is job one: A great sounding amp that breaks down goes from being a favorite piece of gear to a useless piece of crap in less time than it takes to read this sentence." -- BRUCE ZINKY


Top
Profile
Post subject: Re: Blackface Deluxe ("Non-Reverb") - Logo question?
Posted: Thu Oct 10, 2013 3:26 pm
Offline
Hobbyist
Hobbyist
User avatar

Joined: Mon Oct 13, 2008 2:15 pm
Posts: 54
Nikola Tesla wrote:
How would you compare G12C/S and G12C?


Very subtle difference, the "S" has smoother high frequencies, in the Blackface amp, to my ears, this seemed to accentuate some aggressiveness in the mids, while I found the "C" to have a bell-like clarity across the spectrum. Saying that, those same qualities made the "S" the perfect match to the Blues Deluxe, it brings all the benefits of the "C", but softens that top end spike. I'm tempted to buy one more of each for my 2x12. Hope this helps.


Top
Profile
Post subject: Re: Blackface Deluxe ("Non-Reverb") - Logo question?
Posted: Thu Oct 17, 2013 1:33 pm
Offline
Hobbyist
Hobbyist
User avatar

Joined: Mon Oct 13, 2008 2:15 pm
Posts: 54
Well, I got a replacement set of chassis straps, cap cover and a few other bits and pieces tidied up today, so here she is. Sooooo happy :D



Top
Profile
Post subject: Re: Blackface Deluxe ("Non-Reverb") - Logo question?
Posted: Thu Oct 17, 2013 1:36 pm
Offline
Rock Icon
Rock Icon
User avatar

Joined: Wed Mar 31, 2010 12:48 am
Posts: 26417
Location: Tombstone Territory
Many battle scars......it's definitely seen some action.
