Post subject: Re: 1974 Bandmaster Reverb Filter Caps and Resistors
Posted: Mon Apr 29, 2013 7:07 am
Offline
Roadie
Roadie

Joined: Thu Feb 21, 2008 12:52 pm
Posts: 292
Krankster wrote:
Beemer, did the Deoxit routine (good stuph) and new tubes. After going over every solder joint in the amp, touching up several, it pops twice instead of five times when turned of standby. Maybe I'm on the right track. Could new filter caps cause a weak cap or resistor to malfunction. Could a filter cap have an internal short and exhibit this symptom? Thanks, Gracias, Danke Shon, Doppi (my 2 year old daughter).


I am sure you did the chop stick check already by pushing on various areas of the fiber eyelet board to see if you can duplicate the "pop". I have had issues with amps that there is something going on under the board to chassis....excess solder, debris, etc.
What I have done is remove the fiber board hold down screws and slide a few tounge depressors under the board. Dont force them. After all is clear....power up the amp and see if the noise goes away. I have done thins on more than a few amps that were "noisy". Kind of like a last resort and if the prob is there it beats unsoldering and pulling the whole board up the do the work. Just a thought


Top
Profile
Fender Play Winter Sale 2020
Post subject: Re: 1974 Bandmaster Reverb Filter Caps and Resistors
Posted: Mon Apr 29, 2013 8:20 am
Offline
Roadie
Roadie

Joined: Sat Mar 09, 2013 12:27 pm
Posts: 207
That's a good idea. The preamp board has a lot of wax on it-more than any I've seen. Every component is covered. When I took out the old e caps, I had to scrape a little wax off the eyelets. Fender must have let this one soak for a while. Yes, I did the chop stick test. I'll try lifting the board.


Top
Profile
Post subject: Re: 1974 Bandmaster Reverb Filter Caps and Resistors
Posted: Mon Apr 29, 2013 8:54 am
Offline
Roadie
Roadie

Joined: Thu Feb 21, 2008 12:52 pm
Posts: 292
Krankster wrote:
That's a good idea. The preamp board has a lot of wax on it-more than any I've seen. Every component is covered. When I took out the old e caps, I had to scrape a little wax off the eyelets. Fender must have let this one soak for a while. Yes, I did the chop stick test. I'll try lifting the board.

I have seen boards like this before as well. Supposedly its a good idea to heat the board with a hair dryer or carefully with a heat gun to "remelt" the wax. Apparently wax can hold moisture as well as repelling it. Its another thing I had found on the net a while back.


Top
Profile
Post subject: Re: 1974 Bandmaster Reverb Filter Caps and Resistors
Posted: Mon May 06, 2013 7:00 am
Offline
Roadie
Roadie

Joined: Sat Mar 09, 2013 12:27 pm
Posts: 207
She's finally finished. I went through every solder joint, replaced couple wires, two resistors and the popping sound on power up is down to one faint click. I've heard lots of old amps that sound much worse. Anyway, she sounds great and is ready for some real abuse-playing loud (that's why they call me Krank) and roadies. Most amps don't really shine unless you run them at 9. :mrgreen: Thanks for everyone's help. You're a decent buch of felons, I mean fellows.


Top
Profile
Post subject: Re: 1974 Bandmaster Reverb Filter Caps and Resistors
Posted: Mon May 06, 2013 10:54 am
Offline
Rock Star
Rock Star
User avatar

Joined: Sat Jul 03, 2010 2:18 pm
Posts: 6544
Good deal! Glad it worked out for you & the amp.

:D


Top
Profile
Post subject: Re: 1974 Bandmaster Reverb Filter Caps and Resistors
Posted: Mon May 06, 2013 11:00 am
Offline
Rock Icon
Rock Icon
User avatar

Joined: Wed Mar 31, 2010 12:48 am
Posts: 26417
Location: Tombstone Territory
Rawk on!

8)

Arjay

_________________
"Here's why reliability is job one: A great sounding amp that breaks down goes from being a favorite piece of gear to a useless piece of crap in less time than it takes to read this sentence." -- BRUCE ZINKY


Top
Profile
Post subject: Re: 1974 Bandmaster Reverb Filter Caps and Resistors
Posted: Sat May 11, 2013 8:01 pm
Offline
Roadie
Roadie

Joined: Sat Mar 09, 2013 12:27 pm
Posts: 207
A note to all the viewers-

Learn how to work on your old amps. You'll save a boatload of cash and get the sound you're after. If you make a mistake, go back a try again. Learning how to solder is the hardest part. After a while, the schematics will start to make sense. Digital Mutli-Meters are $10-$20-well worth the price and easy to use. Just make sure to drain the caps before you poke around inside. Amp maintanence is like stetting up a guitar-you need to learn how to do it. There's nothing like the sound of a good Fender amp.


Top
Profile
Post subject: Re: 1974 Bandmaster Reverb Filter Caps and Resistors
Posted: Thu May 16, 2013 12:20 pm
Offline
Roadie
Roadie

Joined: Sat Mar 09, 2013 12:27 pm
Posts: 207
While working on the BMR, I noticed one of the 470 ohm 1 watt screen resistors was badly burnt on the ends. I don't know if it was burnt when installed or by heat over time. Since the amp is 40 years old, should I replace both screen resistors-and 1500 ohm grid stoppers while I'm in there?


Top
Profile
Post subject: Re: 1974 Bandmaster Reverb Filter Caps and Resistors
Posted: Thu May 16, 2013 3:01 pm
Offline
Rock Icon
Rock Icon
User avatar

Joined: Wed Mar 31, 2010 12:48 am
Posts: 26417
Location: Tombstone Territory
Yes, by all means.

For durability and reliability, use metal-film type resistors.

Arjay

_________________
"Here's why reliability is job one: A great sounding amp that breaks down goes from being a favorite piece of gear to a useless piece of crap in less time than it takes to read this sentence." -- BRUCE ZINKY


Top
Profile
Post subject: Re: 1974 Bandmaster Reverb Filter Caps and Resistors
Posted: Thu May 16, 2013 5:32 pm
Offline
Rock Star
Rock Star
User avatar

Joined: Sat Jul 03, 2010 2:18 pm
Posts: 6544
Just addendum to Arjay's post --- use flameproof resistors.

Good luck!

http://www.amazon.com/470-Ohm-Flameproo ... pd_sim_e_8


Top
Profile
Post subject: Re: 1974 Bandmaster Reverb Filter Caps and Resistors
Posted: Fri May 17, 2013 9:58 am
Offline
Roadie
Roadie

Joined: Sat Mar 09, 2013 12:27 pm
Posts: 207
FYI, I disconnected one end of the 2000pf caps on the tube sockets. The amp oscillated like crazy and the vibrato ticked. So I reconnected them.-too bad. I've done this successfully on other amps with no ill effects. It made the amps sparkle. Thanks for the suggestions.


Top
Profile
Post subject: Re: 1974 Bandmaster Reverb Filter Caps and Resistors
Posted: Sat May 18, 2013 7:17 pm
Offline
Aspiring Musician
Aspiring Musician
User avatar

Joined: Fri Aug 21, 2009 1:45 pm
Posts: 852
Location: SoCal323
I did the same with my BMR, luckily no oscillation or ticking so I left them out. Luck of the draw I guess. :wink:

_________________
Its a lifestyle.....



Top
Profile
Post subject: Re: 1974 Bandmaster Reverb Filter Caps and Resistors
Posted: Sat Jul 06, 2013 1:38 pm
Offline
Roadie
Roadie

Joined: Sat Mar 09, 2013 12:27 pm
Posts: 207
Here's a pic of the Bandmaster with a 2x12" cab-WGS Veteran 30's. I like the combination of Fender and Celestion speakers.



Top
Profile
Post subject: Re: 1974 Bandmaster Reverb Filter Caps and Resistors
Posted: Wed Jul 10, 2013 10:17 am
Offline
Roadie
Roadie

Joined: Sat Mar 09, 2013 12:27 pm
Posts: 207
One more try with the pic.
