Post subject: Sliver Face Band Master with 4 Power tubes ?
Posted: Sun Dec 14, 2008 8:17 am
Offline
Hobbyist
Hobbyist

Joined: Thu Aug 09, 2007 8:34 pm
Posts: 2
I got a Silver face w/aluminum fram Band Master head with 4 Power tubes at guitar center for $300 Friday. It has a Tube Chart with Model/circiut number ab763 but the tube chart show only two power tubes. Do you think it has been hot rod or a custom Dual Band Master form fender ? The only amp that had 4 power tubes with the same set up as the Band Master was the Dual Showman with the ab763 circiutry. I found schematic at www.freeinfosociety.com for the Showman.


Top
Profile
Fender Play Winter Sale 2020
Post subject:
Posted: Sun Nov 01, 2009 10:39 pm
Offline
Professional Musician
Professional Musician
User avatar

Joined: Sat Dec 13, 2008 11:49 am
Posts: 1153
Location: South Bay, CA
It's not a Bandmaster. Probably a Dual Showman with Bandmaster faceplate. sounds like still a great deal at $300.


Top
Profile
Post subject:
Posted: Mon Nov 02, 2009 8:27 pm
Offline
Hobbyist
Hobbyist

Joined: Thu Aug 09, 2007 8:34 pm
Posts: 2
I have check the transformer numbers and looked inside . It's a hot rod Bandmaster . I found out they used the same chasie's for the Showman ,Dual Showman and Bandmaster.


Top
Profile
Post subject:
Posted: Sun Nov 08, 2009 4:45 pm
Offline
Professional Musician
Professional Musician

Joined: Fri Jun 26, 2009 6:53 pm
Posts: 2252
Location: Harvard IL
Tele, so which transformers are in your amp? My '67 was punched and drilled for 4 power tubes(which made it easy to add a tube rectifier). Don't know why the early '68 Band Masters would not be the same. All the BF Band Masters I've seen on the bench had the 4 hole chassis. In fact, one amp a guy brought in had two sockets and tubes,with nothing attached(bogus). ART

_________________
None of Us are free, if One of Us is chained !


Top
Profile
Post subject:
Posted: Tue Nov 10, 2009 4:44 pm
Offline
Hobbyist
Hobbyist
User avatar

Joined: Mon Sep 22, 2008 9:01 pm
Posts: 86
Location: Long Island, NY
I own an early '68 Bandmaster that I purchased, new, in February of that year. Looking at the original post made me curious so I checked the head. While there are only two power tubes in there, the chassis does, indeed, have an additional two holes punched in it, adjacent to the existing power tubes, with covers screwed on them. So it's very possible that the head is an original Bandmaster that's been worked.


Top
Profile
Post subject:
Posted: Tue Nov 10, 2009 5:18 pm
Offline
Professional Musician
Professional Musician
User avatar

Joined: Sat Dec 13, 2008 11:49 am
Posts: 1153
Location: South Bay, CA
Makes me wonder how many chassis designs they had that are similar in dimensions.

Fender may have punched all similar chassis the same whether it was a Bandmaster, Showman - easier to have one punch setup than several.


Top
Profile
Post subject:
Posted: Tue Nov 10, 2009 8:19 pm
Offline
Professional Musician
Professional Musician

Joined: Fri Jun 26, 2009 6:53 pm
Posts: 2252
Location: Harvard IL
Yeah Neo, I was going to suggest that this was the same chassis as the "short head" Showman, but couldn't verify it. There was an amp that I had to remove the faceplate or the brass grounding plate from, and there was a hole punched for another pot. That might account for the middle control on the Showman. But it was some years ago and I can't say for sure that it was a Band Master. ART

_________________
None of Us are free, if One of Us is chained !


Top
Profile
Post subject:
Posted: Fri Nov 20, 2009 12:10 am
Offline
Professional Musician
Professional Musician
User avatar

Joined: Sat Dec 13, 2008 11:49 am
Posts: 1153
Location: South Bay, CA
Just looked at mine, and as expected, it has 4 tube holes punched out, but the two are covered. Here's an image for others to see.


So, I think Fender had one die press for the Bandmaster, Showman, Dual Showman amps, since they all shared the same chassis.

I like the idea of using one for a tube rectifier - since my ground switch isn't connected anymore after the removal of the "Death Cap,", might be an interesting mod - switch from tube to solid state rectifier.

_________________
'59? Bogen Challenger CHA-33, '65 Bandmaster, '65 Tremolux, 65 Showman;
'74 SF Princeton; '77 SF Princeton Reverb; Dr. Z Mini Z

Our band: http://www.facebook.com/thetoysband


Top
Profile
Post subject:
Posted: Fri Nov 20, 2009 3:36 am
Offline
Professional Musician
Professional Musician

Joined: Fri Jun 26, 2009 6:53 pm
Posts: 2252
Location: Harvard IL
Actually Neo, I turned the B Master into more of a Pro. Always liked those 2X6L6 amps, but couldn't afford one of the brown or blonde amps so.....I made a few adjustments to what I had(don't think Leo would be offended). You know, that Band Master combo is very similar to my Bassman 2X10 combo. If I were more computer savvy, I'd get a pic. ART

_________________
None of Us are free, if One of Us is chained !


Top
